0.15μF 154J 250VAC CBB62 Metallized Polypropylene Film Capacitor Pack of 5pcs
Specification:-
- Rated voltage : 250VAC
- Dimensions = 25.0mm(W)
- Dimensions = 17.0mm(H)
- Dimensions = 11.5mm(T)
- Dimensions = 20.0mm(P)
- Dimensions = 0.8(d)
- Reference Standard = GB/T 14472-98 (IEC 384-14)
- Climatic Category = 40/085/21
- Dissipation Factor = ≤ 0.001 (1kHz, 20°C)
SKU: AN8533E
0.15μF 154J 250VAC CBB62 Metallized Polypropylene Film Capacitor Pack of 5pcs
The characteristics of CBB62 include low spoilage, high outer electric resistance, high voltage endurance, and good self-healing properties. utilized mostly in AC-in networks, AC and impulse circuits of devices, as a voltage-reducing component in AC circuits, and particularly in a variety of low-cost lights and electronic rectifiers. The aluminum-coated aluminum dielectric and aluminum-coated aluminum electrolyte of this capacitor are composed of metalized polypropylene. Its metallized polypropylene film capacitor, non-inductive wound construction, and self-healing effect are intended to shield electronic equipment from damage caused by static and ESD. Ideal for AC applications where minimal loss and a slight intrinsic temperature rise are crucial. This item is a long-lasting, highly conductive, and flexible film capacitor. Low-voltage electronic devices like toys, instruments, and household appliances are perfect for using it. The metalized polypropylene capacitor is a good option for general electronics applications due to its sturdy construction.
Features:
- Very small loss, excellent frequency and temperature characteristics, and high insulation resistance.
- Reliable quality due to self-healing effect.
- As an across-the-line type noise suppression capacitor and suitable for AC purposes.
- Withstanding 2.5 kV impulse voltage, Class X2
- Flame-retardant epoxy resin coating (UL94/V-0)
