Specification:-
- Charging Voltage: DC 4.2V CC/CV
- Max continuous charging current: 10 A
- Over charge detection voltage: 4.25±0.05V
- Over discharge detection voltage: 3.0±0.1V
- Over current detection current: 0.15±0.03V
- Operating Temperature: -45°C to +65°C
- Storage Temperature: -45°C to +85°C
- Model No.(7fd8)
SKU: BF9403A
1S 10A NMC BMS Hardware
The 1S 10A NMC BMS Hardware is a Battery Management System (BMS) designed for a 1-series (1S) Nickel Manganese Cobalt (NMC) battery pack. This system is capable of handling a 10A continuous discharge current, making it suitable for low to medium power applications such as small electric devices, power tools, and portable energy solutions. Key features of this BMS include overcharge protection, over-discharge protection, overcurrent protection, short-circuit protection, and over-temperature protection. These features are essential for ensuring that the battery pack operates safely and effectively. By preventing conditions such as overvoltage, undervoltage, excessive currents, and overheating, the BMS helps safeguard both the battery cells and connected devices from potential damage. This BMS also manages cell balancing, ensuring that the battery pack is kept in a state where all cells operate within a balanced voltage range. This is crucial for maintaining battery health, maximizing performance, and extending the life of the battery pack.
Features:-
- Compact & Lightweight Design
- Overcharge Protection
- Over-discharge Protection
- Overcurrent & Short-Circuit Protection
