220uf 63V Aluminum Electrolytic Capacitors (10 X 20 mm) Pack of 5pcs
Specification
- Rating Voltage = 63V
- Material = Aluminum
- Capacitor Size = 10 x 20 mm
- Impedance (O)max. 20°C 1000KHz = 73
- Ripple current = 520
- DC Leakage Current = ≤ 0.01CV (µF) at 20°C
- Capacitance Tolerance = ±20%(M)
- Shelf Life = After storage for 1000Hrs at +105°C with no voltage applied, the capacitor shell meet the specified limits for “Load Life”.
SKU: HE8532E
220uf 63V Aluminum Electrolytic Capacitors (10 X 20 mm) Pack of 5pcs
The aluminum anode foil's surface determines the capacitance of aluminum electrolytic capacitors. These capacitors have the highest volumetric capacitance of all capacitor technologies because of specific etching techniques that maximize their surface, giving them a desirable cost-per-capacitance ratio. Aluminum electrolytic capacitors made by EPCOS have exceptional characteristics for handling ripple currents and extremely long-term dependability. Frequency converters, wind power converters, solar inverters, professional power supplies, uninterruptible power supplies (UPS), medical applications, professional photoflash units, and various automotive applications all require aluminum electrolytic capacitors. For the majority of applications, they are an affordable, extremely reliable solution.
Features:
- Wide Temperature Range
- Extremely Low Impedance
- High Reliability
- Load Life = 105°C 2000Hrs
- Very excellent ripple current ability and low impedance
- Best Quality Product
