Specification:
- Type: Single turn potentiometer
- Resistance value: 250K
- Number of Pins: 3
- Shaft : D shape shaft
- Rotational Life: 2000K cycles
SKU: UN8533A
250K Rotary potentiometer D shape shaft handle 3 pin Pack of 2
This D-shaped shaft and three-pin rotary potentiometer. It's meant to be mounted on a circuit board. The Rotary Potentiometer is a small, simple-to-use potentiometer for shaft position or angle measurement. Though it can be utilized in digital control systems, among other applications, this rotary potentiometer is a component of a general-purpose voltage and current meter. Easy handling is provided by the handle and D-shaped shaft of this rotary potentiometer. Three pins are also included for easy connection. To control the direction of an electrical signal, you can turn the shaft of this rotary potentiometer in a circular motion. Being three-pin, it can be connected to any other three-pin connector. A three-pin device, the Rotary Potentiometer D-shaped shaft, enables current to flow through a low-resistance channel from the three pins to the ground. Often employed in a wide range of electrical applications, this gadget may measure and control power and sound levels, among other inputs.
Pin configuration
- Fixed End: connected to one end of the resistive track
- Variable End: connected to the wiper to provide variable voltage
- Fixed End: connected to another end of the resistive track
