Specification:-
- Charging Voltage: DC 12.6V CC/CV
- Max continuous charging current: 6A
- Over charge detection voltage: 4.25±0.05V
- Over discharge detection voltage: 2.7±0.08V
- Over current detection current: 0.1±0.03V
- Operating Temperature: -45°C to +65°C
- Storage Temperature: -45°C to +85°C
SKU: DF9403A
3S 6A NMC BMS with Nickel without Bal
The 3S 6A NMC BMS with Nickel without Balancing is a Battery Management System (BMS) designed for 3-series (3S) Nickel Manganese Cobalt (NMC) lithium-ion battery packs. With a 6A continuous discharge current, this BMS is suitable for low-to-medium power applications such as small electric vehicles, energy storage systems, portable power packs, and solar battery systems. This BMS is equipped with essential safety protection features, including overcharge protection, over-discharge protection, overcurrent protection, short-circuit protection, and over-temperature protection. These protections are designed to safeguard the battery pack and connected devices, preventing potential hazards and ensuring the system operates within safe parameters. One notable feature of this 3S 6A NMC BMS is that it does not include active cell balancing, meaning the battery pack is not actively balanced during charging and discharging. While this may limit the system’s ability to optimize individual cell performance over time, it can still be a viable option for applications where battery balancing is not a high priority, and where cost-effectiveness or simplicity is more important.
Features:-
- Compact & Lightweight Design
- Overcharge Protection
- Over-discharge Protection
- Overcurrent & Short-Circuit Protection
