Specification:-
- Number of pin : 6
- Voltage : 60 Volts
- Size : 7x7mm
- Type : Horn Type
- Life : 100,000 times
- Temperature: 40~70°C
- Rated Load: :0.3A 60V AC /1.5A 25V AC
SKU: SO9107A
7x7mm 6-Pin Push Button Horn Type Switch Pack of 1000
The 7x7mm 6-Pin Push Button Horn Type Switch is a compact and versatile component designed for a range of electronic applications. Measuring 7 mm x 7 mm, it features a unique horn-style actuator that offers a distinct and ergonomic pressing experience. This design makes it highly suitable for applications requiring frequent user interaction. Equipped with 6 pins, the switch ensures robust mechanical stability and flexible electrical connectivity, enabling it to be used in various circuit configurations. The pins are designed for seamless integration with PCBs, providing reliable connections and long-term performance. This push button switch is commonly used in control panels, electronic appliances, and DIY projects. It is ideal for tasks such as toggling power, switching modes, or activating specific functions in devices. The horn-type design not only enhances aesthetics but also ensures ease of use, even in compact setups.
Features:-
- Compact Size for Space-Constrained Applications
- Secure and Stable 6-Pin Connection
- Durable Construction for Long-Term Reliability
Discover Your Next Favorite!
AI-Powered Suggestions
Frequently Asked Questions
We offer a wide range of switches including push button switches, toggle switches, momentary switches, self-lock switches, and smart WiFi switch modules. Options come in different sizes (12mm, 16mm, 19mm), colors (blue, green, yellow, white), and indicator lights for versatile applications.
Yes! Our collection includes Mini WiFi Smart Switch Modules that support app and voice control, making them perfect for smart home automation. Additionally, push button and toggle switches are widely used in DIY electronics, robotics, and educational projects.
Yes. Many of our switches come with built‑in LED indicators (blue, green, yellow, white) for Easy status monitoring. These are Especially useful in control panels, machinery, and DIY electronics projects where visibility matters.
We stock nickel‑plated brass push button switches (IP65 rated) and high‑current toggle switches that are suitable for industrial control panels, machinery, and automotive applications. For heavy loads, always check the voltage and current rating before installation.
Consider these factors :
- Type of operation (momentary vs self‑lock)
- Size & mounting hole (12mm, 16mm, 19mm)
- Current & voltage rating (AC 125V 3A, AC 250V 1.5A, etc.)
- Indicator requirement (LED or non‑LED)
- Application (DIY, home automation, industrial use)
Our filters and product Descriptions make it Easy to select the right switch.
. SPST (Single Pole Single Throw): Simple ON/OFF switch.
. SPDT (Single Pole Double Throw): One input, two outputs – used for selecting between two circuits.
DPDT (Double Pole Double Throw) : Controls two separate circuits simultaneously, often used in motor direction control
