Specification:-
- Mounting: SMD
- Number of: 16 Pins
- Guaranteed ±4.5V to ±18V Operation
- CMOS and TTL Logic Compatible
- Monolithic, Low-Power CMOS Design.
SKU: CS8501A
DG201 Quad CMOS Analog Switches SMD IC
The DG201 is a Quad CMOS Analog Switches SMD IC that offers reliable switching capabilities for analog signals in electronic circuits. This IC consists of four independent single-pole, single-throw (SPST) analog switches, controlled digitally to manage signal flow efficiently. Designed for use in signal routing and multiplexing applications, the DG201 is highly suitable for audio, data acquisition, and communication systems. Each switch in the DG201 provides low on-resistance, allowing signals to pass through with minimal distortion or attenuation, ensuring high fidelity for analog signals. The IC operates with a wide voltage range and demonstrates excellent linearity and low leakage, which is essential for maintaining signal integrity in precision applications. Additionally, the DG201 is constructed using CMOS technology, contributing to its low power consumption and suitability for battery-powered devices.
Features:-
- High-Speed Operation
- Wide Operating Voltage Range
- Compact SMD package
