Smart BMS 8-24S 200A Same Port for Charge and Discharge (SP24S004)
Specification:-
- Cell specifications: 8~24 strings of LiFePO4 battery
- Interface type: Charge and discharge are both at the same port
- Charging voltage: 3.60V*Number of strings
- Cell voltage range: 2.20~3.75V
- Continuous charging current: 200A
- Continuous discharging current: 200A
- Consumption of running: ≤20mA
- Operating temperature: -20°C~75°C
SKU: QV9016A
Smart BMS 8-24S 200A Same Port for Charge and Discharge (SP24S004)
The Smart BMS 8-24S 200A Same Port for Charge and Discharge (SP24S004) is a high-performance Battery Management System (BMS) designed for Li-ion and LiFePO4 battery packs with 8 to 24 series (S) configurations. Engineered for high-power applications, it is suitable for electric vehicles (EVs), solar energy storage systems, industrial power backups, and other demanding uses. With a 200A continuous charge and discharge current, this BMS efficiently handles high loads while ensuring stable operation. The same-port design simplifies wiring by using a single connection for charging and discharging, reducing installation complexity. A key feature of the SP24S004 is its smart active balancing, which continuously optimizes individual cell voltages to enhance battery lifespan and performance. Advanced protection mechanisms are integrated, including overcharge, over-discharge, overcurrent, short-circuit, and thermal protection, ensuring safe and reliable battery operation. Additionally, the BMS supports communication protocols such as Bluetooth, UART, and CAN, enabling real-time monitoring and control through a mobile app or external monitoring system. With high-quality MOSFETs and a robust PCB design, this 200A Smart BMS is a durable and efficient choice for high-energy applications, delivering exceptional safety, performance, and longevity.
Features:-
- Overcharge protection
- Over-discharge protection
- Overcurrent protection
- Short-circuit protection
- Same-Port Operation
- High Efficiency & Reliability
