MICRO CONTROLLER IC's

TOP250YN Extended power Flexible design, Eco-Smart, integrated off-line switcher 6 pin IC

Specification

  1. Input supply voltage AC: 85V to 265V
  2. Switching frequency: 66kHz - 132kHz
  3. Output voltage : 12V
  4. Operating supply current : 1.6mA
  5. Drain voltage : 0.3V to 700V
  6. Drain peak current : 10.08A
  7. Type : Off line convertor
  8. Extended power range
  9. Wide duty cycle

SKU: 13003FD

MRP Rs. 389.00
Rs. 269.00 (Incl. Tax)
Rs. 227.97 (+18% GST extra)
Buy to Get ₹0 off!
₹0 Special Discount Applied
Quantity
Add to Cart

TOP250YN Extended power Flexible design, Eco-Smart, integrated off-line switcher 6 pin IC

The TOP250YN is a 135 extend power integrate offline switcher IC. It is used to integrate high voltage power MOSFET, PWM control, fault protection, and other control circuitry onto a single CMOS chip. This IC consists of many new functions to reduce system cost, improve design flexibility, and provide high performance and energy efficiency. Line feed-forward with a maximum duty cycle (DCMAX) reduction rejects line ripple and limits DCMAX at high line.

Features

  1. Eliminate or reduce cost of external components
  2. Fully integrated soft-start for minimum stress/over-shoot
  3. Externally programmable accurate current limit
  4. Wider duty cycle for more power, smaller input capacitor
  5. Line under voltage detection
