DIODE & ZENER

SMC(G) SMCJ70A 1500W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification

1. Case : SMC(G)
2. Stand-off voltage : 70.0V
3. Maximum peak pulse current : 13.3A
4. Maxim reverse current : 5.0µA
5. Maximum clamping voltage : 113V
6. Power dissipation : 1500W

MM1ZB11 500mW ,SOD-123 Packaging Diodes Pack of 5pcs

Specification:

• Power Dissipation : 500mW
• Nominal Zener Voltage : 11V
• Minimum Zener voltage : 10.78V
• Maximum Zener voltage : 11.22V
• Maximum Reverse Current : 0.1µa
• Package : SOD-123

1.5KE12 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

1. Minimum Breakdown voltage: 10.8V
2. Maximum Breakdown voltage: 13.2V
3. Maximum Reverse Leakage Current: 5.0µa
4. Maximum peak pulse current: 87.0A
5. Maximum clamping voltage: 17.3V
6. Maximum Temperature Coefficient of VBR: 0.078%
7. Power Dissipation: 1500W
8. Package: DO-201AD

5KP70A 10µA ,R-6 Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 77.8V
• Maximum Breakdown voltage: 86.0V
• Maximum Reverse Leakage Current: 10µa
• Maximum peak pulse current: 44A
• Maximum clamping voltage: 113V
• Power Dissipation: 5000W
• Package: R-6

1.5KE200 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 180.0V
• Maximum Breakdown voltage: 220.0V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 5.2A
• Maximum clamping voltage: 287.0V
• Maximum Temperature Coefficient of VBR: 0.108%
• Power Dissipation: 1500W
• Package: DO-201AD

P6KE170A 5.0µA, DO-15 Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 162.0V
• Maximum Breakdown voltage: 179.0V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 2.6A
• Maximum clamping voltage: 234.0V
• Maximum Temperature Coefficient of VBR: 0.108%
• Power Dissipation: 600W
• Package: DO-15

DO-15, FR156 800V Fast Recovery Rectifiers Diode pack of 5pcs

Specification

1. Maximum respective peak reverse voltage : 800v
2. Maximum average rectified current : 1.5A
3. Maxim reverse current : 5.0µA
4. Case :  DO-15
5. Non-Repetitive Peak Forward Surge Current : 60A
6. Operating Junction Temperature Range : − 65 to +150°C
7. Maxim forward voltage : 1.5V
8. Maximum reverse recovery time  500ns

SMAJ40A 400W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification:-

1. Package : SMA/SMA(G)
2. Minimum Breakdown voltage : 44.40V
3. Maximum Breakdown voltage : 49.1V
4. Stand-off voltage : 40.0
5. Maximum reverse leakage current : 5.0µa
6. Maximum peak pulse current : 4.7A
7. Maximum clamping voltage : 64.5V
8. Power dissipation : 400W

GNJ6, GBJ1502 15A 200V Bridge Rectifiers Diode pack of 2pcs

Specification

1. Case : GNJ6
2. Maximum respective peak reverse voltage : 200v
3. Maximum average rectified current : 15.0A
4. Maxim reverse current : 10.0µA
5. Non-Repetitive Peak Forward Surge Current : 200A
6. Maxim forward voltage : 1.1V

1.5KE51A 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

1. Minimum Breakdown voltage: 48.5V
2. Maximum Breakdown voltage: 53.6V
3. Maximum Reverse Leakage Current: 5.0µa
4. Maximum peak pulse current: 21.4A
5. Maximum clamping voltage: 70.1V
6. Maximum Temperature Coefficient of VBR: 0.102%
7. Power Dissipation: 1500W
8. Package: DO-201AD

SMC(G) SMCJ40 1500W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification

1. Case : SMC(G)
2. Stand-off voltage : 40.0V
3. Maximum peak pulse current : 21.0A
4. Maxim reverse current : 5.0µA
5. Maximum clamping voltage : 71.4V
6. Power dissipation : 1500W

MM3Z5239B 300mW ,SOD-323 Packaging Diodes Pack of 5pcs

Specification:

• Power Dissipation: 300mW
• Nominal Zener Voltage : 9.1V
• Minimum Zener voltage: 8.65V
• Maximum Zener voltage: 9.56V
• Maximum Reverse Current: 3µa
• Package: SOD-323
