DIODE & ZENER

1.5KE12A 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

1. Minimum Breakdown voltage: 11.4V
2. Maximum Breakdown voltage: 12.6V
3. Maximum Reverse Leakage Current: 5.0µa
4. Maximum peak pulse current: 90.0A
5. Maximum clamping voltage: 16.7V
6. Maximum Temperature Coefficient of VBR: 0.078%
7. Power Dissipation: 1500W
8. Package: DO-201AD

P4KE75A 5.0µA ,DO-41 Transient Voltage Suppressors Pack of 100

Specification:-

• Breakover voltage : Min(V) 71.3 , Max(V) 78.8
• Maximum peak current : 4.1A
• Maximum reverse leakage current @ VRRM : 5.0µA
• Power dissipation :400W
• Package : DO-41

P4KE24A 5.0µA ,DO-41 Transient Voltage Suppressors Pack of 100

Specification:-

• Breakover voltage : Min(V) 22.8 , Max(V) 25.2
• Maximum peak current : 13A
• Maximum reverse leakage current @ VRRM : 5.0µA
• Package : DO-41

DO-201AD, UF5405 500V High Efficiency Rectifiers Diode pack of 5pcs

Specification

1. Maximum respective peak reverse voltage : 500v
2. Maximum average rectified current : 3.0A
3. Maxim reverse current : 5.0µA
4. Case :  DO-201AD
5. Non-Repetitive Peak Forward Surge Current : 150A
6. Maxim forward voltage : 1.7V
7. Maximum reverse recovery time : 75ns

P4KE170A 5.0µA ,DO-41 Transient Voltage Suppressors Pack of 100

Specification:-

• Breakover voltage : Min(V) 162.0 , Max(V) 179.0
• Maximum peak current : 1.8A
• Maximum reverse leakage current @ VRRM : 5.0µA
• Power dissipation :400W
• Package : DO-41

5KP60 10µA ,R-6 Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 66.7V
• Maximum Breakdown voltage: 81.5V
• Maximum Reverse Leakage Current: 10µa
• Maximum peak pulse current: 47A
• Maximum clamping voltage: 107.0V
• Power Dissipation: 5000W
• Package: R-6

SMC(G) SMCJ11A 1500W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification

1. Case : SMC(G)
2. Stand-off voltage : 11.0V
3. Maximum peak pulse current : 82.4A
4. Maxim reverse current : 5.0µA
5. Maximum clamping voltage : 18.2V
6. Power dissipation : 1500W

5KP45A 10µA ,R-6 Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 50.0V
• Maximum Breakdown voltage: 55.3V
• Maximum Reverse Leakage Current: 10µa
• Maximum peak pulse current: 69A
• Maximum clamping voltage: 72.7V
• Power Dissipation: 5000W
• Package: R-6

5KP8.0A 150µA ,R-6 Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 8.89V
• Maximum Breakdown voltage: 9.83V
• Maximum Reverse Leakage Current: 150µa
• Maximum peak pulse current: 367A
• Maximum clamping voltage: 13.6V
• Power Dissipation: 5000W
• Package: R-6

1.5KE56A 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 53.2V
• Maximum Breakdown voltage: 58.8V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 19.5A
• Maximum clamping voltage: 77.0V
• Maximum Temperature Coefficient of VBR: 0.103%
• Power Dissipation: 1500W
• Package: DO-201AD

DO-201AD, FR301G 50V Glass Passivated Fast Recovery Rectifiers Diode pack of 5pcs

Specification

1. Case : DO-201AD
2. Maximum respective peak reverse voltage : 50v
3. Maximum average rectified current : 3.0A
4. Maxim reverse current : 5.0µA
5. Non-Repetitive Peak Forward Surge Current : 200A
6. Maxim forward voltage : 1.3V
7. Maximum reverse recovery time : 150ns

SMAJ40A 400W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification:-

1. Package : SMA/SMA(G)
2. Minimum Breakdown voltage : 44.40V
3. Maximum Breakdown voltage : 49.1V
4. Stand-off voltage : 40.0
5. Maximum reverse leakage current : 5.0µa
6. Maximum peak pulse current : 4.7A
7. Maximum clamping voltage : 64.5V
8. Power dissipation : 400W
