DIODE & ZENER

SMC(G) SMCJ120 1500W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification

1. Case : SMC(G)
2. Stand-off voltage : 120.0V
3. Maximum peak pulse current : 7.0A
4. Maxim reverse current : 5.0µA
5. Maximum clamping voltage : 214V
6. Power dissipation : 1500W

B5818WS 200mW ,SOD-323 Packaging Diodes Pack of 5pcs

Specification:

• Power Dissipation : 200mW
• Maximum repetitive peak reverse voltage : 30V
• Maximum average rectified current : 1000
• Maximum reverse current : 1000µa
• Package : SOD-323

5KP6.5A 2000µA ,R-6 Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 7.22V
• Maximum Breakdown voltage: 7.98V
• Maximum Reverse Leakage Current: 2000µa
• Maximum peak pulse current: 447A
• Maximum clamping voltage: 11.2V
• Power Dissipation: 5000W
• Package: R-6

P4KE13A 5.0µA ,DO-41 Transient Voltage Suppressors Pack of 100

Specification:-

• Breakover voltage : Min(V) 12.4 , Max(V) 13.7
• Maximum peak current : 23A
• Maximum reverse leakage current @ VRRM : 5.0µA
• Package : DO-41

SMBJ36 600W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification:-

1. Package : SMB/SMB(G)
2. Minimum Breakdown voltage : 40.00V
3. Maximum Breakdown voltage : 48.9V
4. Stand-off voltage : 36.0
5. Maximum reverse leakage current : 5.0
6. Maximum peak pulse current : 9.3A
7. Maximum clamping voltage : 64.3V
8. Power dissipation : 600W

SA11A 1.0µA ,DO-15 Transient Voltage Suppressors Pack of 100

Specification:-

• Breakover voltage : Min(V) 12.2 , Max(V) 13.5
• Maximum peak current : 27.4A
• Maximum reverse leakage current @ VRWM : 1.0µA
• Power dissipation :500W
• Package : DO-15

5KP11A 10µA ,R-6 Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 12.2V
• Maximum Breakdown voltage: 13.5V
• Maximum Reverse Leakage Current: 10µa
• Maximum peak pulse current: 274A
• Maximum clamping voltage: 18.2V
• Power Dissipation: 5000W
• Package: R-6

P4KE27A 5.0µA ,DO-41 Transient Voltage Suppressors Pack of 100

Specification:-

• Breakover voltage : Min(V) 25.7 , Max(V) 28.4
• Maximum peak current : 11.2A
• Maximum reverse leakage current @ VRRM : 5.0µA
• Package : DO-41

BZT52C27 500mW ,SOD-123 Packaging Diodes Pack of 5pcs

Specification:

• Power Dissipation : 500mW
• Nominal Zener Voltage : 27.0V
• Minimum Zener voltage : 25.1V
• Maximum Zener voltage : 28.9V
• Maximum Reverse Leakage Current : 0.1µa
• Package : SOD-123

SMBJ30A 600W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification:-

1. Package : SMB/SMB(G)
2. Minimum Breakdown voltage : 33.3V
3. Maximum Breakdown voltage : 36.8V
4. Stand-off voltage : 30.0
5. Maximum reverse leakage current : 5.0
6. Maximum peak pulse current : 12.4A
7. Maximum clamping voltage : 48.4V
8. Power dissipation : 600W

MM1Z5253B 500mW SOD-123 Packaging Diodes Pack of 5pcs

Specification:

• Power Dissipation : 500mW
• Nominal Zener Voltage : 25V
• Minimum Zener voltage : 23.75V
• Maximum Zener voltage : 26.25V
• Maximum Reverse Current : 0.1µa
• Package : SOD-123

1.5KE47 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

1. Minimum Breakdown voltage: 42.3V
2. Maximum Breakdown voltage: 51.7V
3. Maximum Reverse Leakage Current: 5.0µa
4. Maximum peak pulse current: 22.2A
5. Maximum clamping voltage: 67.8V
6. Maximum Temperature Coefficient of VBR: 0.101%
7. Power Dissipation: 1500W
8. Package: DO-201AD
