IC
Showing 1–12 of 777 results
.jpg)
.jpg)
.jpg)
-
![CD4029 Binary Decade Up-Down Counter IC (DIP-16 Package)]()
CD4029 Binary Decade Up-Down Counter IC (DIP-16 Package)
Rs. 29.00Specification:-
- DC Supply Voltage Range, (VDD): -0.5V to +20V
- Input Voltage Range, All Inputs: -0.5V to VDD +0.5V
- DC Input Current, Any One Input: ±10mA
- 5V, 10V and 15V Parametric Ratings
- Operating Temperature Range: -55°C to +125°C
- Storage Temperature Range (TSTG): -65°C to +150°C
- Lead Temperature (During Soldering): +265°C
-
![TLC5940 16-Channel PWM Control LED Driver IC (DIP-28 Package)]()
TLC5940 16-Channel PWM Control LED Driver IC (DIP-28 Package)
Rs. 539.00Specification:-
- No. of Channels: 16
- CMOS Level I/O
- 30 MHz Data Transfer Rate
- Supply voltage range: 3.V to 5.5V
- Drive Capability: 0 mA to 60 mA (VCC < 3.6 V)
- Thermal error flagging
-
![XL7015E1 0.8A 150KHz 80V Buck DC to DC Converter TO-252-5]()
XL7015E1 0.8A 150KHz 80V Buck DC to DC Converter TO-252-5
Rs. 89.00Specification:-
- Mounting: DIP
- Input Voltage Range: Up to 80V
- Output Current: Up to 0.8A
- Switching Frequency: 150KHz
- Output Voltage: Adjustable
-
![TP4056 1A Li-Ion Battery Charger IC]()
TP4056 1A Li-Ion Battery Charger IC
Rs. 29.00Specification:-
- Input Supply Voltage: -0.3V～8V
- Storage temperature: -0.3V～10V
- BAT Pin Current: 1200mA
- PROG Pin Current: 1200uA
- Maximum Junction Temperature: 145℃
- Operating Ambient Temperature Rang: -40 ℃～85℃
- Lead Temp.(Soldering, 10sec: 260℃
-
![LM393 Low Power Low Offset Voltage Dual Comparator OP-AMP SMD IC]()
LM393 Low Power Low Offset Voltage Dual Comparator OP-AMP SMD IC
Rs. 29.00Specification:-
- IC Name: LM393
- Supply Voltage: +36 or ±18
- Differential Input Voltage: 36
- Low Input Bias Current: 25 nA
- Low Input Offset Current: 5.0 nA
- Output Voltage: 36
- Output Sink Current: 20
- Output Short Circuit−to−Ground: Continuous
- Input Common Mode Voltage Range: −0.3 to +36
- Storage Temperature Range: −65 to +150
-
![LF398 Sample and Hold Op-Amplifier IC (DIP-8 Package)]()
LF398 Sample and Hold Op-Amplifier IC (DIP-8 Package)
Rs. 79.00Specification:-
- Supply Voltage: ±18 V
- Input voltage: ±18 V
- Power dissipation: 500 m W
- Operates from ±5-V to ±18-V Supplies
- 0.5-mV Typical Hold Step at Ch = 0.01 µF
- Logic-to-logic reference differential voltage: 7 to -30 V
- Storage temperature: -65 °C to 150 °C
-
![CD4059 Programmable Divide-by-N Counter IC (DIP-24 Package)]()
CD4059 Programmable Divide-by-N Counter IC (DIP-24 Package)
Rs. 169.00Specification:-
- Function: Counter
- Voltage: 3V to 18V
- 5-V and 10-V parametric ratings
- Max. input leakage current of 1 µA at 15 volts
- Operating temperature range: -55°C to 125 °C
- Synchronous Programmable N Counter:N = 3 to 9999 or 15,999
-
![CD4043 Quad NOR R-S Latch Tri-state IC (DIP-16 Package)]()
CD4043 Quad NOR R-S Latch Tri-state IC (DIP-16 Package)
Rs. 29.00Specification:-
- Supply Voltage (VDD): −0.5V to +18V
- Input Voltage (VIN): −0.5V to VDD +0.5V
- Storage Temperature Range (TS): −65°C to +150°C
- Power Dissipation (PD) Dual-In-Line: 700 mW
- Lead Temperature (TL): 260°C
-
![CD4040 12-Stage Ripple Carry Binary Counter IC (DIP-16 Package)]()
CD4040 12-Stage Ripple Carry Binary Counter IC (DIP-16 Package)
Rs. 29.00Specification:-
- Type: Binary
- Function: Counter
- Supply Voltage: 3V to +18V
- Noise margin (over full package-temperature range):
- 1 V at VDD = 5 V
- 2 V at VDD = 10 V
- 2.5 V at VDD = 15 V
- 5-V, 10-V, and 15-V parametric ratings
- Storage Temperature Range (TS): −55°C to +125°C
-
![IR2110 High and Low Side Driver SMD IC]()
IR2110 High and Low Side Driver SMD IC
Rs. 139.00Specification:-
- High-side floating supply voltage: -0.3 to 525 V
- High-side floating supply offset voltage: VB -25 to VB +0.3 V
- High-side floating output voltage: VS -0.3 to VB +0.3 V
- Low side and logic fixed supply voltage: -0.3 to 25 V
- Low side output voltage: -0.3 to VCC+0.3 V
- Logic supply voltage: -0.3 to VSS+25 V
-
![ADE7753 Single-Phase Multi-Function Metering SMD IC]()
ADE7753 Single-Phase Multi-Function Metering SMD IC
Rs. 409.00Specification:-
- Mounting: SMD
- Number of: 20 Pins
- Reference 2.4 V with external overdrive capability
- Single 5 V supply, low power (25 mW typical)
- On-chip temperature sensor (±3°C typical)
- Interrupt request pin (IRQ) and status register
-
![MAX660 CMOS Monolithic Voltage Converter IC]()
MAX660 CMOS Monolithic Voltage Converter IC
Rs. 449.00Specification:-
- Supply Voltage (V+ to GND, or GND to OUT): +6V
- Storage Temperature Range: -65°to +160°C
- Lead Temperature: +300°C
- Frequency: 10kHz/80kHz
- Operating Temperature Ranges: 0°C to +70°C
- Continuous Power Dissipation: 727mW
- Output Short-Circuit Duration to GND: 1 sec
- OUT and V+ Continuous Output Current: 120mA
