IC
Showing 1–12 of 949 results
.jpg)
5.jpg)
-
![74HC109 Dual J-K Positive-Edge-Triggered Flip-Flops SMD IC]()
74HC109 Dual J-K Positive-Edge-Triggered Flip-Flops SMD IC
Rs. 29.00Specification:-
- Mounting: SMD
- Power Dissipation: 500 mW
- Supply Voltage: − 0.5 to + 7.0V
- Input Clamping Current: ±20 mA
- Output Clamping Current: ±20 mA
- J and K inputs for easy D-type flip-flop
- Storage Temperature Range : −65°C to + 150°C
-
![CD4538 Dual Precision Monostable Multi Vibrator IC (DIP-16 Package)]()
CD4538 Dual Precision Monostable Multi Vibrator IC (DIP-16 Package)
Rs. 29.00Specification:-
- Part number: CD4538
- Wide supply voltage range 3.0V to 15V
- High noise immunity 0.45 VCC (typ.)
- DC Supply Voltage (VDD): −0.5V to +18VDC
- Input Voltage (VIN): −0.5V to VDD + 0.5VDC
- Power Dissipation (PD) Dual-In-Line: 700 mW
- Lead Temperature (TL): 260°C
- Storage Temperature Range (TS): −65°C to +150°C
-
![LMC660 CMOS Quad Operational Amplifier SMD IC]()
LMC660 CMOS Quad Operational Amplifier SMD IC
Rs. 169.00Specification:-
- Slew Rate: 1.1 V/μs
- Specified for 2 kΩ and 600Ω Loads
- High Voltage Gain: 126 dB
- Low Input Offset Voltage: 3 mV
- Ultra Low Input Bias Current: 2 fA
- Low Distortion: 0.01% at 10 kHz
- Operating Range from +5V to +15.5V Supply
-
![74LS10 Dual J-K Positive Edge-Triggered Flip-Flop IC DIP-16 Package]()
74LS10 Dual J-K Positive Edge-Triggered Flip-Flop IC DIP-16 Package
Rs. 29.00Specification:-
- Number of pins: 16
- Supply Voltage (VCC): 7 V
- Input Voltage (VI): 7 V
- Operating free-air temperature range: 0°C to 70°C
- Storage temperature range: -65°C to 150°C
-
![80C51BH-1 Microcontroller IC 8-Bit MROM 8051 CPU 16MHz CMOS 40-PDIP]()
80C51BH-1 Microcontroller IC 8-Bit MROM 8051 CPU 16MHz CMOS 40-PDIP
Rs. 500.00Specification:-
- Package: PDIP40 (0.600", 15.24mm)
- Microcontroller Bit: 8-Bit
- MROM, CPU Architecture: 8051 CPU
- Clock Speed: 16 MHz
- Technology: CMOS
-
![AM26LV32 Low-Voltage High-Speed Quadruple Differential Line Receiver SMD IC]()
AM26LV32 Low-Voltage High-Speed Quadruple Differential Line Receiver SMD IC
Rs. 169.00Specification:-
- Mounting: SMD
- Number of: 16 Pins
- Input Hysteresis: 50 mV Typical
- Operates From Single 3.3-V Supply
- Ultra-Low Power Dissipation: 27 mW Typical
- Switching Rates Up to 32 MHz
- 235 mW With Four Receivers at 32 MHz
-
![AM2147-55DC 4096 x 1 Static RAM 55ns NMOS 18-CDIP Memory IC]()
AM2147-55DC 4096 x 1 Static RAM 55ns NMOS 18-CDIP Memory IC
Rs. 500.00Specification:-
- Package: 18-pin CDIP
- Technology: NMOS
- Supply Voltage-Max (Vsup): 5.5 V
- Supply Voltage-Min (Vsup): 4.5 V
- Supply Voltage-Nom (Vsup): 5 V
- Supply Current-Max 0.18 mA
- Terminal Position: Dual
- Memory Density: 4096 bit
-
![74LS153 Dual 1-of-4 Line Data Selector/Multiplexer IC DIP-16 Package]()
74LS153 Dual 1-of-4 Line Data Selector/Multiplexer IC DIP-16 Package
Rs. 29.00Specification:-
- Number of pins: 16
- Supply Voltage (VCC): 7 V
- Input Voltage (VI): 7 V
- Operating free-air temperature range: 0°C to +70°C
- Storage temperature range: -65°C to +150°C
- Typical power dissipation 31 mW
-
![MCP41010 8-Bit Digital 10K Potentiometer with SPI Interface IC]()
MCP41010 8-Bit Digital 10K Potentiometer with SPI Interface IC
Rs. 359.00Specification:-
- Single supply operation: 2.7V – 5.5V
- All inputs and outputs w.r.t. VSS: -0.6V to VDD +1.0V
- Storage temperature: -60°C to +150°C
- Ambient temp. with power applied: -60°C to +125°C
- ESD protection on all pins: ≥ 2 kV
-
![AM27C256-120JI EPROM OTP Memory IS 256 Bit Parallel 120ns 32-PLCC (14x11.46)]()
AM27C256-120JI EPROM OTP Memory IS 256 Bit Parallel 120ns 32-PLCC (14x11.46)
Rs. 500.00Specification:-
- Technology: CMOS
- Memory Density: 16384 bit
- Number of Terminals: 32 PLCC
- Supply Voltage-Max (Vsup): 5.5 V
- Supply Voltage-Min (Vsup): 4.5 V
- Supply Voltage-Nom (Vsup): 5 V
- Supply Current-Max: 0.03 mA
-
![INA106 Difference Op-Amplifier IC (DIP-8 Package)]()
INA106 Difference Op-Amplifier IC (DIP-8 Package)
Rs. 849.00Specification:-
- Packages: 8-Pin
- Power Supply Voltage: +18V
- Input Voltage Range: ±VS
- Storage Temperature Range: –40°C to +85°C
- Lead Temperature: +300°C
- Accurate Gain: ±0.025% max
- Operating Temperature Range: +260°C
-
![CD4052 Differential 4-Channel Multiplexer/Demultiplexer IC (DIP-16 Package)]()
CD4052 Differential 4-Channel Multiplexer/Demultiplexer IC (DIP-16 Package)
Rs. 29.00Specification:-
- DC Supply Voltage (VDD) : −0.5VDC to +18VDC
- Input Voltage (VIN) : −0.5VDC to VDD + 0.5VDC
- Storage Temperature Range (TS) : −65°C to +150°C
- Power Dissipation (PD) Dual-In-Line: 700 mW
- Lead Temperature (TL) : 260°C
- Matched switch characteristics: ∆RON = 5Ω (typ.) for VDD − VEE = 15V
- High “OFF” resistance: channel leakage of ±10 pA (typ.) at VDD − VEE = 10V
