BMS HARDWARE

Showing 1–12 of 223 results

  • 3S 6A NMC BMS with Nickel without Bal
    BMS HARDWARE
    3S 6A NMC BMS with Nickel without Bal
    Rs. 69.00

    Specification:-

    • Charging Voltage: DC 12.6V CC/CV
    • Max continuous charging current: 6A
    • Over charge detection voltage: 4.25±0.05V
    • Over discharge detection voltage: 2.7±0.08V
    • Over current detection current: 0.1±0.03V
    • Operating Temperature: -45°C to +65°C
    • Storage Temperature: -45°C to +85°C
    • Model No.(7fda)
    (1)
    Rs. 69.00
  • Smart BMS 8-24S 40A Same Port for Charge and Discharge (SP24S007)
    BMS HARDWARE
    Smart BMS 8-24S 40A Same Port for Charge and Discharge (SP24S007)
    Rs. 4079.00

    Specification:-

    • Cell specifications: 8~24 strings of LiFePO4 battery
    • Charging voltage: 3.60V*Number of strings
    • Cell voltage range: 2.20~3.75V
    • Continuous charging current: 40A
    • Continuous discharging current: 40A
    • Consumption of running: ≤20mA
    • Model No.(51a4)
    (1)
    Rs. 4079.00
  • 4S 80AMP LFP BMS Hardware (ZP04S016)
    BMS HARDWARE
    4S 80AMP LFP BMS Hardware (ZP04S016)
    Rs. 1219.00

    Specification:-

    • Model: ZP04S016
    • Charging voltage: 3.6V Number of strings
    • Cell voltage range: 2.20~3.75V
    • Continuous charging current: 30A
    • Continuous discharging current: 60A
    • Consumption of running: ≤150uA
    • -Circuit resistance: ≤10mR
    • Operating temperature:-20°C-75°C
    • Model no. (7ffb)
    (1)
    Rs. 1219.00
  • Smart BMS 8-24S 50A Same Port for Charge and Discharge (SP24S007)
    BMS HARDWARE
    Smart BMS 8-24S 50A Same Port for Charge and Discharge (SP24S007)
    Rs. 4539.00

    Specification:-

    • Cell specifications: 8~24 strings of LiFePO4 battery
    • Charging voltage: 3.60V*Number of strings
    • Cell voltage range: 2.20~3.75V
    • Continuous charging current: 50A
    • Continuous discharging current: 50A
    • Consumption of running: ≤20mA
    • Model No.( 4946)
    (1)
    Rs. 4539.00
  • 12S 20A BMS LFP Hardware Waterproof
    BMS HARDWARE
    12S 20A BMS LFP Hardware Waterproof
    Rs. 939.00

    Specification:-

    • Battery Configuration: 12S for LiFePO4 (LFP) batteries
    • Continuous Discharge Current: 20A
    • Over-Voltage Protection: 3.8V
    • Balancing Current: 50mA
    • Charge Voltage: 43.8V
    • Model no. (124d)
    (1)
    Rs. 939.00
    Join Waitlist
  • 4S 200AMP LFP BMS Hardware (ZP04S006)
    BMS HARDWARE
    4S 200AMP LFP BMS Hardware (ZP04S006)
    Rs. 3829.00

    Specification:-

    • Model: ZP04S006
    • Cell voltage range: 2.20~3.75V
    • Continuous discharging current: 100A
    • Consumption of running: ≤200uA
    • -Circuit resistance: ≤10mR
    • Operating temperature: -20°C-75°C
    • Model no. (7d3e)
    (1)
    Rs. 3829.00
  • 8-17S 100A Smart Active Balance Li-Ion-LiFePO4 BMS (R24TK1A)
    BMS HARDWARE
    8-17S 100A Smart Active Balance Li-Ion-LiFePO4 BMS (R24TK1A)
    Rs. 5949.00

    Specification:-

    • Model Number: R24TK1A (763e)
    • Cell sampling voltage range: 1.5V-4.9V
    • Operating voltage range: >10V
    • Balance method: Active Balance
    • Working power consumption: ≤1.25W
    • working temperature: -40°C~85°C
    (1)
    Rs. 5949.00
  • 8S 60AMP LFP BMS Hardware (ZP10S036)
    BMS HARDWARE
    8S 60AMP LFP BMS Hardware (ZP10S036)
    Rs. 1109.00

    Specification:-

    • Model: ZP10S036
    • Charging voltage: 3.6V Number of strings
    • Cell voltage range: 2.0~3.75V
    • Continuous charging current: 30A
    • Continuous discharging current: 60A
    • Consumption of running: ≤100uA
    • -Circuit resistance: ≤20mR
    • Operating temperature: -20°C-75°C
    • Model no. (76b8)
    (1)
    Rs. 1109.00
    Join Waitlist
  • 4S 60AMP LFP BMS Hardware (ZP04S016)
    BMS HARDWARE
    4S 60AMP LFP BMS Hardware (ZP04S016)
    Rs. 1099.00

    Specification:-

    • Charging voltage: 3.6V Number of strings
    • Cell voltage range: 2.20–3.75V
    • Continuous charging current: 30A
    • Continuous discharging current: 60A
    • Consumption of running: ≤150uA
    • -Circuit resistance: ≤10mR
    • Operating temperature: -20°C~75°C
    • Model no. (79cc)
    (1)
    Rs. 1099.00
  • 8-24S 100A Smart Active Balance Li-Ion-LiFePO4 BMS (R24TK1A)
    BMS HARDWARE
    8-24S 100A Smart Active Balance Li-Ion-LiFePO4 BMS (R24TK1A)
    Rs. 6239.00

    Specification:-

    • Model Number: R24TK1A (7642)
    • Cell sampling voltage range: 1.5V-4.9V
    • Operating voltage range: >10V
    • Balance method: Active Balance
    • Working power consumption: ≤1.25W
    • Working temperature: -40°C~85°C
    (1)
    Rs. 6239.00
  • 16S 100A BMS NMC Hardware Waterproof
    BMS HARDWARE
    16S 100A BMS NMC Hardware Waterproof
    Rs. 4059.00

    Specification:-

    • Continuous Discharge Current: 100A
    • Over-Voltage Protection: 4.2V
    • Charge Current: 20A
    • Charge Voltage: 67.2V
    • Battery Configuration: 16S for NMC (Nickel Manganese Cobalt) Lithium-Ion
    • Model no. (0fff)
    (1)
    Rs. 4059.00
    Join Waitlist
  • 4S 10A NMC BMS Module with Balance Hardware
    BMS HARDWARE
    4S 10A NMC BMS Module with Balance Hardware
    Rs. 119.00

    Specification:-

    • Charging Voltage: DC 8.4V CC/CV
    • Max continuous charging current: 10 A
    • Over charge detection voltage: 4.25±0.05V
    • Over discharge detection voltage: 3.0±0.1V
    • Over current detection current: 0.15±0.03V
    • Operating Temperature: -45°C to +65°C
    • Storage Temperature: -45°C to +85°C
    • Model No.(7fdd)
    (1)
    Rs. 119.00
