HBDS1-AF-11D/24V/G Plastic Body Push Button Switch with Green Indicator
Specification:-
- Product model: HBDS1-AF-11D/24V/G
- Head Shape: Square
- Mounting holes: 16mm
- Rated voltage: 24V
- Waterproof: IP40/IP65
- Terminal type: Pin terminal
- Contact resistance: ≤50 mΩ
- Insulation resistance: ≥100MΩ
- Working environment temperature: -25℃～+65℃
SKU: NH9606A
HBDS1-AF-11D/24V/G Plastic Body Push Button Switch with Green Indicator
The HBDS1-AF-11D/24V/G Plastic Body Push Button Switch with Green Indicator is a high-performance, low-voltage control switch designed for electrical panels, automation systems, and industrial control applications. Featuring a durable plastic body, this switch is lightweight, corrosion-resistant, and built to withstand exposure to dust and moisture—making it suitable for both indoor and semi-industrial environments. Operating on 24V DC, the switch is ideal for low-voltage systems, including battery-operated equipment and control boards where electrical safety and energy efficiency are priorities. It includes a bright green LED indicator, which illuminates when the button is pressed, providing immediate visual feedback. The green color typically signifies a safe condition, “on” status, or readiness for operation. This model features a 1NO + 1NC contact configuration (one normally open and one normally closed), offering flexible integration into various circuit types. Its momentary action means the button returns to its original position after activation, ideal for applications like start/stop controls or signal triggering. With a standard panel-mount design, the HBDS1-AF-11D/24V/G is easy to install and configure. Whether you're designing a new control system or upgrading an existing one, this push button switch delivers reliability, clarity, and user-friendly operation in a compact form.
Feature:-
- Momentary Operation
- Durable Plastic Body
- Panel Mount Design
- Dust and Moisture Resistant
- Space-saving design fits well in confined panel layouts.
- Contact Configuration: 1NO + 1NC (One Normally Open and One Normally Closed contact) for versatile control options.
