HBDS1-AY-11DZ/220V/R Plastic Body Round Push Button Switch with Red Indicator
Specification:-
- Product model: HBDS1-AY-11DZ/220V/R
- Head Shape: Round
- Mounting Hole Size: 16mm
- Rated voltage: 220V
- Rated current: 5A
- Switch Value: Ith: 5A, UI: 250V
- Waterproof: IP40/IP65
- Terminal type: Pin terminal
- Contact resistance: ≤50 mΩ
- Insulation resistance: ≥100MΩ
- Working environment temperature: -25℃～+65℃
SKU: SL9606A
HBDS1-AY-11DZ/220V/R Plastic Body Round Push Button Switch with Red Indicator
The HBDS1-AY-11DZ/220V/R Plastic Body Round Push Button Switch with Red Indicator is a durable and visually striking component engineered for reliable control in industrial and commercial applications. Operating on 220V AC, this push button features a bright red LED indicator, universally recognized as a signal for “stop,” “alert,” or “emergency” functions in control systems. The illuminated red indicator provides immediate visual feedback, enhancing safety by drawing attention to critical operational states. Constructed with a high-strength plastic body, this switch is designed to withstand the rigors of heavy-duty use, including resistance to impact, dust, and general wear. It is equipped with a 1NO+1NC contact configuration, allowing for both normally open and normally closed control circuit operations—ideal for complex automation needs or dual-function systems. The momentary action of the switch means it returns to its default position after being pressed, which is perfect for applications that require short-term engagement like resets, stops, or operator alerts. The DZ marking typically indicates added robustness, such as dustproofing, for more demanding environments. Designed to fit standard 16mm panel cutouts, the HBDS1-AY-11DZ/220V/R combines ease of installation, operational reliability, and clear visual signaling, making it an essential part of any industrial control interface.
Feature:-
- Momentary Operation
- Durable Plastic Body
- Panel Mount Design
- Dust and Moisture Resistant
- Space-saving design fits well in confined panel layouts.
