HBDS1-AY-11DZ/24V/W Plastic Body Round Push Button Switch with White Indicator
Specification:-
- Product model: HBDS1-AY-11DZ/24V/W
- Head Shape: Round
- Mounting Hole Size: 16mm
- Rated voltage: 24V
- Waterproof: IP40/IP65
- Terminal type: Pin terminal
- Contact resistance: ≤50 mΩ
- Insulation resistance: ≥100MΩ
- Working environment temperature: -25℃～+65℃
SKU: HX9606A
HBDS1-AY-11DZ/24V/W Plastic Body Round Push Button Switch with White Indicator
The HBDS1-AY-11DZ/24V/W Plastic Body Round Push Button Switch with White Indicator is a high-quality control component designed for industrial and commercial applications that require reliable user input and clear status indication. Featuring a durable plastic housing, this switch is engineered to withstand daily operational stress while maintaining consistent performance in control panels, machinery interfaces, and automation systems. Operating on 24V DC, it includes an integrated white LED indicator that provides bright, easy-to-see illumination, which is particularly useful in low-light environments or to indicate a neutral or standby status. The round actuator ensures a comfortable and responsive pressing experience, making it suitable for frequent use. The switch features a 1NO+1NC contact configuration, allowing it to simultaneously open and close separate electrical circuits. This makes it versatile for various applications, such as start/stop functions, equipment enable/disable features, or safety interlocks. With a momentary action, the button returns to its default position after being pressed, enhancing safety and preventing unintended continuous operation. Its compact design fits standard panel cutouts, ensuring straightforward installation and integration into existing setups.
Feature:-
- Momentary Operation
- Durable Plastic Body
- Panel Mount Design
- Dust and Moisture Resistant
- Space-saving design fits well in confined panel layouts.
