HBDS1-AF-11D/24V/Y Plastic Body Push Button Switch with Yellow Indicator
Specification:-
- Product model: HBDS1-AF-11D/24V/Y
- Head Shape: Square
- Mounting holes: 16mm
- Rated voltage: 24V
- Waterproof: IP40/IP65
- Terminal type: Pin terminal
- Contact resistance: ≤50 mΩ
- Insulation resistance: ≥100MΩ
- Working environment temperature: -25℃～+65℃
SKU: WY9606A
HBDS1-AF-11D/24V/Y Plastic Body Push Button Switch with Yellow Indicator
The HBDS1-AF-11D/24V/Y Plastic Body Push Button Switch with Yellow Indicator is a compact and durable control device tailored for low-voltage electrical circuits and automation systems. Featuring a 24V DC operating voltage, this push button is suitable for use in various industrial, commercial, and DIY electronics applications that require safe, efficient control functionality. Housed in a sturdy plastic body, the switch is designed to withstand everyday environmental factors such as dust, humidity, and mechanical stress. It includes a vivid yellow LED indicator, which lights up when the switch is engaged—providing clear and immediate visual feedback to operators. Yellow indicators are typically used to denote warnings, standby modes, or intermediate statuses, making this switch particularly effective for alert and signal-based setups. This model comes with a 1NO + 1NC contact configuration, offering one normally open and one normally closed circuit, which allows for flexible wiring and integration into complex control systems. The momentary action design means the switch returns to its default position after being pressed, making it ideal for functions such as initiating commands, temporary overrides, or toggling intermediate signals.
Feature:-
- Momentary Operation
- Durable Plastic Body
- Panel Mount Design
- Dust and Moisture Resistant
- Space-saving design fits well in confined panel layouts.
- Contact Configuration: 1NO + 1NC (One Normally Open and One Normally Closed contact) for versatile control options.
