HBDS1-AF-11DZ/220V/R Plastic Body Push Button Switch with Red Indicator
Specification:-
- Product model: HBDS1-AF-11DZ/220V/R
- Head Shape: Square
- Mounting Hole Size: 16mm
- Rated voltage: 220V
- Rated current: 5A
- Switch Value: Ith: 5A, UI: 250V
- Waterproof: IP40/IP65
- Terminal type: Pin terminal
- Contact resistance: ≤50 mΩ
- Insulation resistance: ≥100MΩ
- Working environment temperature: -25℃～+65℃
SKU: MS9606A
HBDS1-AF-11DZ/220V/R Plastic Body Push Button Switch with Red Indicator
The HBDS1-AF-11DZ/220V/R Plastic Body Push Button Switch with Red Indicator is a robust and efficient control device designed for industrial and commercial electrical systems operating at 220V AC. Featuring a durable plastic housing, this switch offers resistance to dust, moisture, and mechanical impacts, making it suitable for various environments. Equipped with a bright red LED indicator, the switch provides clear visual feedback upon activation, commonly used to signify "stop" or "emergency" statuses in control systems. The momentary action mechanism ensures the button returns to its default position after being pressed, ideal for applications like machinery start/stop controls or signal triggering. The switch includes a 1NO + 1NC contact configuration, offering flexibility in circuit design. With a standard 16mm mounting hole, it allows for easy installation in control panels, machinery, or DIY projects. The HBDS1-AF-11DZ/220V/R combines reliability, safety, and user-friendly operation, making it a practical choice for various control applications.
Feature:-
- Momentary Operation
- Durable Plastic Body
- Panel Mount Design
- Dust and Moisture Resistant
- Space-saving design fits well in confined panel layouts.
- Contact Configuration: 1NO + 1NC (One Normally Open and One Normally Closed contact) for versatile control options.
