HBDS1-AF-11DZ/24V/B Plastic Body Push Button Switch with Blue Indicator
Specification:-
- Product model: HBDS1-AF-11DZ/24V/B
- Head Shape: Square
- Mounting Hole Size: 16mm
- Rated voltage: 24V
- Waterproof: IP40/IP65
- Terminal type: Pin terminal
- Contact resistance: ≤50 mΩ
- Insulation resistance: ≥100MΩ
- Working environment temperature: -25℃～+65℃
SKU: MU9606A
HBDS1-AF-11DZ/24V/B Plastic Body Push Button Switch with Blue Indicator
The HBDS1-AF-11DZ/24V/B Plastic Body Push Button Switch with Blue Indicator is a versatile and reliable control component designed for industrial and commercial electrical systems. Operating at 24V, this push button switch features a blue LED indicator that offers immediate visual feedback, enhancing user awareness and system diagnostics. Its plastic body ensures lightweight construction while maintaining durability, making it suitable for various environments, including control panels, automation systems, and machinery interfaces. this model is built with a momentary action mechanism, meaning it returns to its original position once released, ideal for tasks like triggering temporary commands, start/stop operations, or control signaling. The standard 16mm mounting hole makes it easy to install into most panels and enclosures, while the contact configuration of 1NO+1NC provides flexibility for integrating with different circuit requirements. The blue indicator is commonly used to represent "on", "power", or "information" states, making it an ideal choice where clear communication of status is necessary. Its snap-action contacts ensure reliable switching performance with minimal wear, contributing to the longevity of the component. Whether you're upgrading an existing system or designing a new control interface, this push button switch delivers both functionality and aesthetics in a compact, cost-effective package.
Feature:-
- Momentary Operation
- Durable Plastic Body
- Panel Mount Design
- Dust and Moisture Resistant
- Space-saving design fits well in confined panel layouts.
- Contact Configuration: 1NO + 1NC (One Normally Open and One Normally Closed contact) for versatile control options.
Find Some Matches!
AI-Powered Suggestions
Frequently Asked Questions
We offer a wide range of switches including push button switches, toggle switches, momentary switches, self-lock switches, and smart WiFi switch modules. Options come in different sizes (12mm, 16mm, 19mm), colors (blue, green, yellow, white), and indicator lights for versatile applications.
Yes! Our collection includes Mini WiFi Smart Switch Modules that support app and voice control, making them perfect for smart home automation. Additionally, push button and toggle switches are widely used in DIY electronics, robotics, and educational projects.
Yes. Many of our switches come with built‑in LED indicators (blue, green, yellow, white) for Easy status monitoring. These are Especially useful in control panels, machinery, and DIY electronics projects where visibility matters.
We stock nickel‑plated brass push button switches (IP65 rated) and high‑current toggle switches that are suitable for industrial control panels, machinery, and automotive applications. For heavy loads, always check the voltage and current rating before installation.
Consider these factors :
- Type of operation (momentary vs self‑lock)
- Size & mounting hole (12mm, 16mm, 19mm)
- Current & voltage rating (AC 125V 3A, AC 250V 1.5A, etc.)
- Indicator requirement (LED or non‑LED)
- Application (DIY, home automation, industrial use)
Our filters and product Descriptions make it Easy to select the right switch.
. SPST (Single Pole Single Throw): Simple ON/OFF switch.
. SPDT (Single Pole Double Throw): One input, two outputs – used for selecting between two circuits.
DPDT (Double Pole Double Throw) : Controls two separate circuits simultaneously, often used in motor direction control
