HBDS1-AF-11DZ/24V/G Plastic Body Push Button Switch with Green Indicator
Specification:-
- Product model: HBDS1-AF-11DZ/24V/G
- Head Shape: Square
- Mounting Hole Size: 16mm
- Rated voltage: 24V
- Waterproof: IP40/IP65
- Terminal type: Pin terminal
- Contact resistance: ≤50 mΩ
- Insulation resistance: ≥100MΩ
- Working environment temperature: -25℃～+65℃
SKU: ON9606A
HBDS1-AF-11DZ/24V/G Plastic Body Push Button Switch with Green Indicator
The HBDS1-AF-11DZ/24V/G Plastic Body Push Button Switch with Green Indicator is a high-performance control device designed to meet the needs of modern industrial and electrical applications. Operating at 24V, this push button switch features a green LED indicator, which provides a clear visual signal, often representing power on, go, or system readiness. The green illumination ensures quick and easy recognition of the switch status, enhancing both safety and operational efficiency. Constructed with a durable plastic body, the switch offers resistance to wear, corrosion, and environmental elements, making it ideal for long-term use in a variety of settings such as machinery control panels, automation systems, or factory equipment. The momentary action design means the button returns to its original position after being pressed, suitable for temporary activation of circuits. Equipped with a 1NO + 1NC contact configuration, the switch allows for flexible integration into different control circuit layouts. Its compact size and standard 16mm mounting diameter make installation simple and compatible with most panels. The crisp tactile response and reliable electrical contacts ensure dependable performance even under frequent operation. This model combines practicality, safety, and modern design, making it a reliable choice for industrial control systems.
Feature:-
- Momentary Operation
- Durable Plastic Body
- Panel Mount Design
- Dust and Moisture Resistant
- Space-saving design fits well in confined panel layouts.
- Contact Configuration: 1NO + 1NC (One Normally Open and One Normally Closed contact) for versatile control options.
Find Some Matches!
AI-Powered Suggestions
Frequently Asked Questions
We offer a wide range of switches including push button switches, toggle switches, momentary switches, self-lock switches, and smart WiFi switch modules. Options come in different sizes (12mm, 16mm, 19mm), colors (blue, green, yellow, white), and indicator lights for versatile applications.
Yes! Our collection includes Mini WiFi Smart Switch Modules that support app and voice control, making them perfect for smart home automation. Additionally, push button and toggle switches are widely used in DIY electronics, robotics, and educational projects.
Yes. Many of our switches come with built‑in LED indicators (blue, green, yellow, white) for Easy status monitoring. These are Especially useful in control panels, machinery, and DIY electronics projects where visibility matters.
We stock nickel‑plated brass push button switches (IP65 rated) and high‑current toggle switches that are suitable for industrial control panels, machinery, and automotive applications. For heavy loads, always check the voltage and current rating before installation.
Consider these factors :
- Type of operation (momentary vs self‑lock)
- Size & mounting hole (12mm, 16mm, 19mm)
- Current & voltage rating (AC 125V 3A, AC 250V 1.5A, etc.)
- Indicator requirement (LED or non‑LED)
- Application (DIY, home automation, industrial use)
Our filters and product Descriptions make it Easy to select the right switch.
. SPST (Single Pole Single Throw): Simple ON/OFF switch.
. SPDT (Single Pole Double Throw): One input, two outputs – used for selecting between two circuits.
DPDT (Double Pole Double Throw) : Controls two separate circuits simultaneously, often used in motor direction control
