HBDS1-AY-11D/220V/R Plastic Body Round Push Button Switch with Red Indicator
Specification:-
- Product model: HBDS1-AY-11D/220V/R
- Head Shape: Round
- Mounting Hole Size: 16mm
- Rated voltage: 220V
- Rated current: 5A
- Switch Value: Ith: 5A, UI: 250V
- Waterproof: IP40/IP65
- Terminal type: Pin terminal
- Contact resistance: ≤50 mΩ
- Insulation resistance: ≥100MΩ
- Working environment temperature: -25℃～+65℃
SKU: NN9606A
HBDS1-AY-11D/220V/R Plastic Body Round Push Button Switch with Red Indicator
The HBDS1-AY-11D/220V/R Plastic Body Round Push Button Switch with Red Indicator is a reliable and visually striking control component designed for safety and emergency signaling in industrial and commercial electrical systems. Operating at 220V, this round push button features a vivid red LED indicator, universally recognized for indicating “stop,” “fault,” or “emergency” conditions. The illuminated red lens provides clear, immediate visual feedback, helping operators respond quickly in critical situations. Constructed from high-quality, impact-resistant plastic, the switch is built to withstand harsh operating environments while remaining lightweight and easy to install. The momentary action function ensures that the button automatically returns to its default position after being pressed, making it ideal for applications like emergency stops, system resets, or process interruptions that require temporary input. It includes a 1NO + 1NC (Normally Open + Normally Closed) contact setup, offering versatile wiring options for both activation and feedback circuits. The 22mm standard panel mounting size allows for seamless integration into most control panels, operator stations, and industrial machinery. With its durable construction, intuitive color signaling, and dependable electrical performance, the HBDS1-AY-11D/220V/R is an excellent choice for ensuring both safety and efficiency in your control systems.
Feature:-
- Momentary Operation
- Durable Plastic Body
- Panel Mount Design
- Dust and Moisture Resistant
- Space-saving design fits well in confined panel layouts.
