HBDS1-AY-11D/24V/G Plastic Body Round Push Button Switch with Green Indicator
Specification:-
- Product model: HBDS1-AY-11D/24V/G
- Head Shape: Round
- Mounting Hole Size: 16mm
- Rated voltage: 24V
- Waterproof: IP40/IP65
- Terminal type: Pin terminal
- Contact resistance: ≤50 mΩ
- Insulation resistance: ≥100MΩ
- Working environment temperature: -25℃～+65℃
SKU: BI9606A
HBDS1-AY-11D/24V/G Plastic Body Round Push Button Switch with Green Indicator
The HBDS1-AY-11D/24V/G Plastic Body Round Push Button Switch with Green Indicator is a compact, reliable control device designed for various industrial and commercial applications. Featuring a vibrant green LED indicator, it operates at 24 volts and offers clear visual feedback, making it ideal for signaling power-on, go, or ready states in automated systems. The round push button is made from high-quality polycarbonate, ensuring durability and resistance to environmental factors, while maintaining a sleek and professional appearance. It incorporates a 1NO + 1NC contact configuration (one normally open and one normally closed), providing versatile wiring options for different control schemes. This switch uses momentary (spring-return) action, which returns to its original position after being pressed, making it perfect for momentary activation tasks such as starting machines or triggering alarms. Its silver alloy contacts ensure excellent electrical conductivity and longevity, while the LED indicator consumes minimal power (≤20mA) and offers a long operational life of approximately 50,000 hours. With a mounting hole size of 16mm and pin terminals for easy installation, the HBDS1-AY-11D/24V/G is a practical solution for control panels, automation equipment, and other electronic projects requiring a robust, visually distinct push button interface. Its IP40 protection rating suits most indoor environments.
Feature:-
- Momentary Operation
- Durable Plastic Body
- Panel Mount Design
- Dust and Moisture Resistant
- Space-saving design fits well in confined panel layouts.
