HBDS1-AY-11D/24V/Y Plastic Body Round Push Button Switch with Yellow Indicator
Specification:-
- Product model: HBDS1-AY-11D/24V/Y
- Head Shape: Round
- Mounting Hole Size: 16mm
- Rated Voltage: 24V
- Rated Current: ≤20mA
- Waterproof: IP40/IP65
- Terminal type: Pin terminal
- Contact resistance: ≤50 mΩ
- Insulation resistance: ≥100MΩ
- Working environment temperature: -25℃～+65℃
SKU: BD9606A
HBDS1-AY-11D/24V/Y Plastic Body Round Push Button Switch with Yellow Indicator
The HBDS1-AY-11D/24V/Y Plastic Body Round Push Button Switch with Yellow Indicator is a durable and efficient control device designed for industrial and commercial applications. This push button switch operates at 24 volts and features a prominent round actuator with a bright yellow LED indicator, which enhances visibility and is typically used for functions such as caution signals, intermediate states, or system warnings. The yellow illumination clearly communicates system status to operators, improving safety and response time in complex operations. Constructed from high-quality, impact-resistant plastic, the HBDS1-AY-11D/24V/Y is engineered to withstand demanding working environments, including control panels, machinery interfaces, and automation systems. The switch features a 1NO+1NC contact arrangement, offering versatile configuration options for integrating into various control circuits. It operates as a momentary switch, returning to its original position when released, making it ideal for temporary commands like reset, acknowledgement, or mode shift. The switch supports panel mounting with a standard 16mm cutout, ensuring compatibility with widely used enclosures and control boxes. Easy-to-connect terminals simplify installation and maintenance. With a long mechanical and electrical lifespan, combined with low-power LED operation, this yellow push button offers both reliability and energy efficiency, making it a practical solution for a range of signaling and control applications.
Feature:-
- Momentary Operation
- Durable Plastic Body
- Panel Mount Design
- Dust and Moisture Resistant
- Space-saving design fits well in confined panel layouts.
