SB120 20V 1A Through Hole Diode Rectifiers DO-41 / DO-204AL / AXIAL
Specification:-
- Package: DO-41 / DO-204AL / AXIAL
- Forward Current: 1 A
- Repetitive Reverse Voltage: 20 V
- Forward Voltage: 500 mV
- Forward Surge Current: 40 A
- Reverse Current: 500 uA
SKU: NX8535A
SB120 20V 1A Through Hole Diode Rectifiers DO-41 / DO-204AL / AXIAL
The SB120 is a 20V, 1A through-hole diode rectifier housed in a DO-41 package (also referred to as DO-204AL or AXIAL). This versatile rectifier diode is primarily used for AC to DC conversion in low-power electronic circuits, offering a reliable and efficient solution for power rectification in various applications. With a reverse voltage rating of 20V, the SB120 can handle voltage spikes up to this limit, making it ideal for circuits where the voltage remains within this range. Its current rating of 1A means it can effectively handle moderate current levels, suitable for low-power applications such as small power supplies, battery charging circuits, and low-power motors. The SB120 offers low forward voltage drop and high efficiency, reducing power loss during operation. The DO-41 package provides a compact form factor, suitable for through-hole mounting on circuit boards and easy integration into a variety of designs. Its axial leads ensure secure and stable connection to the circuit, contributing to long-term reliability.
Feature:-
- Guard Ring Die Construction for Transient Protection
- High Current Capability
- Low Power Loss, High Efficiency
- High Surge Current Capability
