General Instrument

General Instrument

Show more >>

Product Categories

BRIDGE RECTIFIER SCHOTTKY BARRIER RECTIFIERS TRANSIENT VOLTAGE SUPPRESSORS

General Instrument

Showing 1–12 of 15 results

Filters

General Instrument

1N5820 20V ,DO-201AD Schottky Barrier Rectifiers Pack of 5pcs

24% OFF

Rs. 29.00
General Instrument

SR530/SB530 30V ,DO-201AD Schottky Barrier Rectifiers Pack of 5pcs

31% OFF

Rs. 29.00
General Instrument

B40C800DM 65V Through Hole Bridge Rectifier Single Phase Standard DFM / 4-EDIP

19% OFF

Rs. 500.00

Join Waitlist
General Instrument

BY500-200 200V 5A Through Hole Diode Rectifiers DO-201AD / AXIAL

25% OFF

Rs. 500.00

Join Waitlist
General Instrument

1.5KE56A/4 77V Ipp 19.7A Ipp Through Hole Transient Voltage Suppressors DO-27

19% OFF

Rs. 500.00

Join Waitlist
General Instrument

SB120 20V 1A Through Hole Diode Rectifiers DO-41 / DO-204AL / AXIAL

17% OFF

Rs. 500.00

Join Waitlist
General Instrument

P6KE33 47.99V Ipp Through Hole Transient Voltage Suppressors DO-15

29% OFF

Rs. 500.00

Join Waitlist
General Instrument

P4KE36A 137V 11.1A Ipp Through Hole Transient Voltage Suppressors DO-27

31% OFF

Rs. 500.00

Join Waitlist
General Instrument

SA85A 137V 3.8A Ipp Through Hole Transient Voltage Suppressors DO-15

31% OFF

Rs. 500.00

Join Waitlist
General Instrument

SA170C 288.75V Ipp 1.9A Ipp Through Hole Transient Voltage Suppressors DO-15

16% OFF

Rs. 500.00

Join Waitlist
General Instrument

P6KE56A 77V Ipp 7.9A Ipp Through Hole Transient Voltage Suppressors DO-15

33% OFF

Rs. 500.00

Join Waitlist
General Instrument

MBR3060PT 60V 30A Through Hole Diode Array 1 Pair Common Cathode TO-247-3

28% OFF

Rs. 500.00

Join Waitlist

General Instrument

1N5820 20V ,DO-201AD Schottky Barrier Rectifiers Pack of 5pcs

Rs. 29.00

Specification:-

Maximum repetitive peak reverse voltage : 20V

Maximum average rectified current : 3.0A

Peak forward surge current 8.3ms single half sine- wave : 80A

Maximum reverse current @ VRRM TA = 25°C : 0.5mA

Package : DO-201AD

(1)
Rs. 29.00
General Instrument

SR530/SB530 30V ,DO-201AD Schottky Barrier Rectifiers Pack of 5pcs

Rs. 29.00

Specification:-

Maximum repetitive peak reverse voltage : 30V

Maximum average rectified current : 5.0A

Peak forward surge current 8.3ms single half sine- wave : 150A

Maximum reverse current @ VRRM TA = 25°C : 0.5mA

Package : DO-201AD

(1)
Rs. 29.00
General Instrument

B40C800DM 65V Through Hole Bridge Rectifier Single Phase Standard DFM / 4-EDIP

Rs. 500.00

Specification:-

Package: EDIP4 (0.321", 8.15mm)

Type: Single Phase Bridge

Mounting Style: Through Hole

Peak Reverse Voltage: 65 V

Vf - Forward Voltage: 1 V

Max Surge Current: 45 A

(1)
Rs. 500.00

Join Waitlist
General Instrument

BY500-200 200V 5A Through Hole Diode Rectifiers DO-201AD / AXIAL

Rs. 500.00

Specification:-

Package: DO-201AD / AXIAL

Reverse Voltage: 200 V

Forward Current: 5 A

Forward Voltage: 1.3 V

Forward Surge Current: 200 A

Reverse Current: 5 uA

(1)
Rs. 500.00

Join Waitlist
General Instrument

1.5KE56A/4 77V Ipp 19.7A Ipp Through Hole Transient Voltage Suppressors DO-27

Rs. 500.00

Specification:-

Package: DO-27 / DO-201AA / AXIAL

Number of Channels: 1 Channel

Working Voltage: 47.8V

Clamping Voltage: 77 V

Breakdown Voltage: 53.2 V

Ipp - Peak Pulse Current: 19.5 A

Pppm - Peak Pulse Power Dissipation: 1.5 kW

(1)
Rs. 500.00

Join Waitlist
General Instrument

SB120 20V 1A Through Hole Diode Rectifiers DO-41 / DO-204AL / AXIAL

Rs. 500.00

Specification:-

Package: DO-41 / DO-204AL / AXIAL

Forward Current: 1 A

Repetitive Reverse Voltage: 20 V

Forward Voltage: 500 mV

Forward Surge Current: 40 A

Reverse Current: 500 uA

(1)
Rs. 500.00

Join Waitlist
General Instrument

P6KE33 47.99V Ipp Through Hole Transient Voltage Suppressors DO-15

Rs. 500.00

Specification:-

Package: DO-15 / DO-204AC / AXIAL

Number of Channels: 1 Channel

Working Voltage: 26.8V

Clamping Voltage: 47.7 V

Breakdown Voltage: 29.7 V

Ipp - Peak Pulse Current: 13 A

Pppm - Peak Pulse Power Dissipation: 600 W

(1)
Rs. 500.00

Join Waitlist
General Instrument

P4KE36A 137V 11.1A Ipp Through Hole Transient Voltage Suppressors DO-27

Rs. 500.00

Specification:-

Package:DO-27 / DO-201AA / AXIAL

Number of Channels: 1 Channel

Working Voltage: 30.8 V

Clamping Voltage: 49.9 V

Breakdown Voltage: 34.2 V

Ipp - Peak Pulse Current: 8.2 A

Pppm - Peak Pulse Power Dissipation: 400 W

(1)
Rs. 500.00

Join Waitlist
General Instrument

SA85A 137V 3.8A Ipp Through Hole Transient Voltage Suppressors DO-15

Rs. 500.00

Specification:-

Package:DO-15 / DO-204AC / AXIAL

Number of Channels: 1 Channel

Working Voltage: 85 V

Clamping Voltage: 137 V

Breakdown Voltage: 94.4 V

Ipp - Peak Pulse Current: 3.7 A

Pppm - Peak Pulse Power Dissipation: 500W

(1)
Rs. 500.00

Join Waitlist
General Instrument

SA170C 288.75V Ipp 1.9A Ipp Through Hole Transient Voltage Suppressors DO-15

Rs. 500.00

Specification:-

Package: DO-15 / DO-204AC / AXIAL

Number of Channels: 1 Channel

Working Voltage: 170V

Clamping Voltage: 301 V

Breakdown Voltage: 231 V

Ipp - Peak Pulse Current: 1.9 A

Pppm - Peak Pulse Power Dissipation: 500W

(1)
Rs. 500.00

Join Waitlist
General Instrument

P6KE56A 77V Ipp 7.9A Ipp Through Hole Transient Voltage Suppressors DO-15

Rs. 500.00

Specification:-

Package: DO-15 / DO-204AC / AXIAL

Number of Channels: 1 Channel

Working Voltage: 47.8V

Clamping Voltage: 77 V

Breakdown Voltage: 53.2 V

Ipp - Peak Pulse Current: 7.9 A

Pppm - Peak Pulse Power Dissipation: 600 W

(1)
Rs. 500.00

Join Waitlist
General Instrument

MBR3060PT 60V 30A Through Hole Diode Array 1 Pair Common Cathode TO-247-3

Rs. 500.00

Specification:-

Package: TO-247-3

Forward Current: 15 A

Repetitive Reverse Voltage: 60 V

Forward Voltage: 750 mV

Forward Surge Current: 200 A

Reverse Current: 1 mA

(1)
Rs. 500.00

Join Waitlist
