DIODE & ZENER

SMBJ75A 600W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification:-

1. Package : SMB/SMB(G)
2. Minimum Breakdown voltage : 83.30V
3. Maximum Breakdown voltage : 92.1V
4. Stand-off voltage : 75.0
5. Maximum reverse leakage current : 5.0
6. Maximum peak pulse current : 5.0A
7. Maximum clamping voltage : 121.0V
8. Power dissipation : 600W

1.5KE180 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 5Pcs

Specification:

• Minimum Breakdown voltage: 162.0V
• Maximum Breakdown voltage: 198.0V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 5.8A
• Maximum clamping voltage: 258.0V
• Maximum Temperature Coefficient of VBR: 0.108%
• Power Dissipation: 1500W
• Package: DO-201AD

1.5KE82A 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 5Pcs

Specification:

• Minimum Breakdown voltage: 77.9V
• Maximum Breakdown voltage: 86.1V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 13.3A
• Maximum clamping voltage: 113.0V
• Maximum Temperature Coefficient of VBR: 0.105%
• Power Dissipation: 1500W
• Package: DO-201AD

P4KE16A 5.0µA ,DO-41 Transient Voltage Suppressors Pack of 5pcs

Specification:-

• Breakover voltage : Min(V) 15.2 , Max(V) 16.8
• Maximum peak current : 19A
• Maximum reverse leakage current @ VRRM : 5.0µA
• Package : DO-41

P4KE8.2A 200µA ,DO-41 Transient Voltage Suppressors Pack of 5pcs

Specification:-

• Breakover voltage : Min(V) 7.79 , Max(V) 8.61
• Maximum peak current : 35A
• Maximum reverse leakage current @ VRRM : 200µA
• Package : DO-41

GBJ6, GBJ1006 10A 600V Bridge Rectifiers Diode pack of 2pcs

Specification

1. Case : GBJ6
2. Maximum respective peak reverse voltage : 600v
3. Maximum average rectified current : 10.0A
4. Maxim reverse current : 10.0µA
5. Non-Repetitive Peak Forward Surge Current : 170A
6. Maxim forward voltage : 1.05V

1.5KE68A 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 5Pcs

Specification:

• Minimum Breakdown voltage: 64.6V
• Maximum Breakdown voltage: 71.4V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 16.3A
• Maximum clamping voltage: 92.0V
• Maximum Temperature Coefficient of VBR: 0.104%
• Power Dissipation: 1500W
• Package: DO-201AD

R-6, FR601 50V Fast Recovery Rectifiers Diode pack of 5pcs

Specification

1. Maximum respective peak reverse voltage : 50v
2. Maximum average rectified current : 6.0A
3. Maxim reverse current : 10µA
4. Case :  R-6
5. Non-Repetitive Peak Forward Surge Current : 300A
6. Operating Junction Temperature Range : − 65 to +150°C
7. Maxim forward voltage : 1.3V
8. Maximum reverse recovery time  150ns

SMBJ18 600W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification:-

1. Package : SMB/SMB(G)
2. Minimum Breakdown voltage : 20.0V
3. Maximum Breakdown voltage : 24.4V
4. Stand-off voltage : 18.0
5. Maximum reverse leakage current : 5.0
6. Maximum peak pulse current : 18.6A
7. Maximum clamping voltage : 32.2V
8. Power dissipation : 600W

SMBJ7.0A 600W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification:-

1. Package : SMB/SMB(G)
2. Minimum Breakdown voltage : 7.78V
3. Maximum Breakdown voltage : 8.60V
4. Stand-off voltage : 7.0
5. Maximum reverse leakage current : 200
6. Maximum peak pulse current : 50.0A
7. Maximum clamping voltage : 12.0V
8. Power dissipation : 600W

SMAJ54A 400W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification:-

1. Package : SMA/SMA(G)
2. Minimum Breakdown voltage : 60.00V
3. Maximum Breakdown voltage : 66.3V
4. Stand-off voltage : 54.0
5. Maximum reverse leakage current : 5.0
6. Maximum peak pulse current : 3.4A
7. Maximum clamping voltage : 87.1V
8. Power dissipation : 400W

GBJ6, GBJ3501 35A 100V Bridge Rectifiers Diode pack of 2pcs

Specification

1. Case : GBJ6
2. Maximum respective peak reverse voltage : 100v
3. Maximum average rectified current : 35.0A
4. Maxim reverse current : 10.0µA
5. Non-Repetitive Peak Forward Surge Current : 350A
6. Maxim forward voltage : 1.1V
