OP-AMP IC
Showing 1–12 of 91 results
-
![INA122 Single Supply Instrumentation Op-Amplifier IC (DIP-8 Package)]()
INA122 Single Supply Instrumentation Op-Amplifier IC (DIP-8 Package)
Rs. 699.00Specification:-
- Low offset voltage: 175 μV maximum
- Wide Supply Range: 2.2V to 36V
- Dual Supply: –0.9/+1.3V to ±18V
- Low Offset Voltage: 250-μV Maximum
- Low Offset Drift: 3-μV/°C Maximum
- Low Noise: 60 nV/√Hz
- Low Input Bias Current: 25-nA Maximum
- Storage temperature: -40°C to 85 °C
-
![PAM8403 Audio Amplifier IC SOP-16 Package]()
PAM8403 Audio Amplifier IC SOP-16 Package
Rs. 59.00Specification:-
- Voltage Supply: 2.8V ~ 5.5V
- Output Type: 2-Channel (Stereo)
- Mounting Type: Surface Mount
- Operating Temperature: -40°C ~ 85°C (TA)
- Package / Case: 16-SOIC (0.154″, 3.90mm Width)
-
![OP07 Ultralow Offset Voltage Op-Amplifier IC (DIP-8 Package)]()
OP07 Ultralow Offset Voltage Op-Amplifier IC (DIP-8 Package)
Rs. 29.00Specification:-
- Supply Voltage (VS): ±22 V
- Differential Input Voltage: ±30 V
- Input Voltage: ±22 V
- Storage Temperature Range: −65°C to +125°C
- Operating Temperature Range: −0°C to +70°C
- Junction Temperature: 150°C
- Lead Temperature, Soldering (60 sec): 300°C
-
![LM393 Low Power Low Offset Voltage Dual Comparator OP-AMP SMD IC]()
LM393 Low Power Low Offset Voltage Dual Comparator OP-AMP SMD IC
Rs. 29.00Specification:-
- IC Name: LM393
- Supply Voltage: +36 or ±18
- Differential Input Voltage: 36
- Low Input Bias Current: 25 nA
- Low Input Offset Current: 5.0 nA
- Output Voltage: 36
- Output Sink Current: 20
- Output Short Circuit−to−Ground: Continuous
- Input Common Mode Voltage Range: −0.3 to +36
- Storage Temperature Range: −65 to +150
-
![CA3130 CMOS Op-Amplifier IC (DIP-8 Package)]()
CA3130 CMOS Op-Amplifier IC (DIP-8 Package)
Rs. 59.00Specification:-
- DC Supply Voltage: 16 V
- Differential Input Voltage: 8 V
- DC Input Voltage: (V+ +8V) to (V- -0.5V)
- Input-Terminal Current: 1mA
- Operating Temperature Range: -50°C to 125°C
- Output Short-Circuit Duration: Indefinite
-
![CA3140 BiMOS Op-Amplifier SMD IC]()
CA3140 BiMOS Op-Amplifier SMD IC
Rs. 99.00Specification:-
- Supply voltage: 4V to 36V
- Directly Replaces Industry Type 741 in Most Application
- Operation at supply voltages up to 36V (18V).
- Very High Input Impedance (ZIN) -1.5T (Typ)
- Very Low Input Current -10pA (Typ) at 15V
-
![TL082 JFET Input Operational Amplifier IC (DIP-8 Package)]()
TL082 JFET Input Operational Amplifier IC (DIP-8 Package)
Rs. 29.00Specification:-
- Number of channels: 2
- Iq per channel: 1.4 (mA)
- Rail-to-rail In to V+
- Low Input Bias Current: 30 pA Typical
- Low Input Offset Current: 5 pA Typica
- Low Power Consumption: 1.4 mA/ch Typical
- Wide Common-Mode and Differential Voltage Ranges
-
![MC33078 Dual High Speed Low Noise Op-Amplifier IC (DIP-8 Package)]()
MC33078 Dual High Speed Low Noise Op-Amplifier IC (DIP-8 Package)
Rs. 179.00Specification:-
- Supply voltage (VCC+): 18 V
- Supply voltage (VCC-): -18 V
- Input current: ±10 m A
- Supply voltage (VCC+ to VCC-): 36 V
- Low Noise Voltage 4.5 nV/√Hz
- Large Output-Voltage Swing 14.1 V to
- Storage temperature range: –65°C to150 °C
-
![INA125 Instrumentation Amplifier with Precision Voltage Reference SMD IC]()
INA125 Instrumentation Amplifier with Precision Voltage Reference SMD IC
Rs. 709.00Specification:-
- Supply Voltage: 36V
- Input Signal Voltage: ±40V
- Output Short Circuit: Continuous
- Operating Temperature: –55°C to +125°C
- Storage Temperature: –55°C to +125°C
- Lead Temperature DIP: +300°C
- Low Quiescent Current: 460µa
- Low Offset Drift: 2µv/°C Max
-
![LM324 Low Power Quad Op-Amp SMD IC]()
LM324 Low Power Quad Op-Amp SMD IC
Rs. 29.00Specification:-
- IC Name: LM324
- Supply Voltage: 32V
- Differential Input Voltage: 32V
- Input Voltage: −0.3V to +32V
- Operating Temperature Range: −25˚C to +85˚C
- Storage Temperature Range: −65˚C to +150˚C
- Lead Temperature DIP: 260˚C
-
![LF353 Wide Bandwidth Dual JFET Input Op-Amplifier IC (DIP-8 Package)]()
LF353 Wide Bandwidth Dual JFET Input Op-Amplifier IC (DIP-8 Package)
Rs. 59.00Specification:-
- Number of channels: 2
- Rail-to-rail In to V+
- Low Input Bias Current 50 pA Typical
- Low Input Noise Current 0.01 pA/√Hz Typical
- Low Supply Current 3.6 mA Typical
- High Input Impedance 1012 Ω Typical
- Internally-Trimmed Offset Voltage
- Gain Bandwidth 3 MHz Typical
- High Slew Rate 13 V/µs Typical
- Storage temperature: 0 °C to 70 °C
-
![INA118 Low Power Instrumentation Op-Amplifier IC (DIP-8 Package)]()
INA118 Low Power Instrumentation Op-Amplifier IC (DIP-8 Package)
Rs. 1119.00Specification:-
- Packages: 8-Pin
- Supply Voltage: ±18 V
- Analog input voltage : ±40 V
- Wide supply range: ±1.35 to ±18 V
- Low quiescent current: 350 µA
- Low offset voltage: 50 µV, maximum
- Low drift: 0.5 µV/°C, maximum
- Low input bias current: 5 nA, maximum
- Storage temperature: -40°C to 125 °C
