Specification:-
- Supply voltage: 4V to 36V
- Directly Replaces Industry Type 741 in Most Application
- Operation at supply voltages up to 36V (18V).
- Very High Input Impedance (ZIN) -1.5T (Typ)
- Very Low Input Current -10pA (Typ) at 15V
SKU: OX8543A
CA3140 BiMOS Op-Amplifier SMD IC
The CA3140 BiMOS operational amplifier is a versatile integrated circuit designed to provide the benefits of both bipolar and MOSFET transistors. This hybrid construction allows it to combine high input impedance and ultra-low input current characteristics of MOSFETs with the high-gain performance typical of bipolar transistors. The result is an op-amp that offers superior speed and precision, making it ideal for applications where low input bias current and high output swing are essential. This op-amp can operate at supply voltages from 4V to 36V, providing flexibility across a wide range of circuits, including single or dual supply operations. With an input impedance exceeding several teraohms and input currents as low as 10 pA, the CA3140 is particularly suitable for use in sensor amplifiers, data acquisition systems, and sample-and-hold circuits. It features a high slew rate of approximately 9 V/µs and a gain-bandwidth product of 4.5 MHz, enabling fast and accurate signal amplification.
Features:-
- High-Speed Operation
- Wide Operating Voltage Range
- Compact SMD package
- Fully Differential Circuit Topology
