TO-126 TRANSISTOR
Showing 1–12 of 144 results
-
A966 Bipolar PNP transistors box of 2000pcs
Rs. 3299.00Specifications
- Transistor type : bipolar PNP transistor
- Collector-Emitter Voltage : -30V
- Collector-Base Voltage : -30V
- Emitter-Base Voltage : -5V
- Collector Current : -1.5A
- Collector Dissipation : -0.9W
- DC Current Gain : - 100 to 320
- Transition Frequency : - 120MHz
-
BC337 Amplifiers NPN transistors box of 2000pcs
Rs. 2649.00Specification
- Transistor type : General Purpose NPN Amplifier Transistor
- Current Gain : 100 to 630
- Continuous Collector current : 800mA
- Collector-Emitter voltage : 45 V
- Collector-Base voltage : 50V
- Emitter Base Voltage : 5V
-
A42 Bipolar NPN transistors box of 2000pcs
Rs. 2979.00Specification
- Transistor type : Bipolar NPN Transistor
- DC Current Gain : 40
- Continuous Collector current : 500mA
- Base- Emitter Voltage : 6V
- Collector-Emitter Voltage : 300V
-
5 mm infrared receivers black color 2 pins pack of 100pcs
Rs. 419.00Specification
- Spectral range : 700-1050
- Light Current : ≥3mA
- Breakdown Voltage : 30
- Maximum forward current : 25mA
- Power dissipation : 100
- Maximum reverse voltage : 5V
- Maximum Forward Voltage : 1.2 V-1.3V
- Package includes : 100 pieces
-
9015 Bipolar PNP transistors box of 2000pcs
Rs. 2649.00Specification
- Transistor Type : 9015 Bipolar PNP transistor
- Max Collector Current : -100mA
- Max Collector-Emitter Voltage : -45V
- Max Collector-Base Voltage : -50V
- Max Emitter-Base Voltage : -5V
- Max Collector Dissipation : 400mW
-
2N3906 General Purpose PNP Transistor Pack of 5
Rs. 49.00Specifications:-
- Collector emitter voltage: -40V
- Collector base voltage: -40V
- Emitter base voltage: -5V
- Collector current: -200mA
- Collector dissipation: -625mW
- Transition frequency: 250MHz
- Noise Figure: – 4dB
-
MJE350 300V PNP Bipolar Power Transistor (TO-126 Package) Pack of 5
Rs. 99.00Specification:-
- Package Type: TO-126
- Transistor type: NPN
- Maximum collector current (IC): –5A
- Maximum collector-emitter voltage (VCE): –300V
- Maximum base collector voltage (VCB): –300V
- Maximum base-emitter voltage (VEBO): –5V
- Maximum collector dissipation (Pc): 20W
-
2SB772 30V 3A 100MHz Bipolar (BJT) Transistor PNP Through Hole SOT-32-3 / TO-225AA / TO-126-3
Rs. 500.00Specification:-
- Package/Case: SOT-32-3 / TO-225AA / TO-126-3
- Mount: Through Hole
- Number of Pins: 3
- Polarity: PNP
- Power Max: 12.5 W
- Frequency - Transition: 100 MHz
- Current Collector (Max): 3A
- Voltage Collector Emitter Breakdown (Max): 30V
-
BD137-16 60V 1.5A 1.25W Through Hole Bipolar Transistor NPN SOT-32-3 / TO-225AA / TO-126-3
Rs. 500.00Specification:-
- Package/Case: SOT-32-3 / TO-225AA / TO-126-3
- Type of transistor: NPN
- Polarisation: bipolar
- Collector-emitter voltage: 60V
- Collector current: 1.5A
- Power dissipation: 12.5W
-
BD138-16 PNP 60V 1.5A 1.25W Through Hole Bipolar Transistor TO-126
Rs. 500.00Specification:-
- Package: SOT-32-3 / TO-225AA / TO-126-3
- Transistor Type: PNP
- Max Collector-Emitter Voltage: -60V
- Max Collector-Base Voltage: -60V
- Max Emitter-Base Voltage: -5V
- Max Collector Dissipation: 12.5 Watt
- Max Transition Frequency: 190 MHz
-
BD179 NPN 80V 3A 3MHz 30W Through Hole Bipolar Transistor TO-126
Rs. 500.00Specification:-
- Package: SOT-32-3 / TO-225AA / TO-126-3
- Collector-Base Voltage: 80V
- Collector-Emitter Voltage: 80V
- Emitter-Base Voltage: 5V
- Collector Current: 3A
- Base Current: 7A
- Total Dissipation: 30W
- Storage Temperature: -65 to 150 C
-
BD178 PNP 60V 3A 3MHz 3W Through Hole Bipolar Transistor TO-126
Rs. 500.00Specification:-
- Package: SOT-32-3 / TO-225AA / TO-126-3
- Transistor Type: PNP
- Collector-Emitter Voltage, max: -60 V
- Collector-Base Voltage, max: -60 V
- Emitter-Base Voltage, max: -5 V
- Collector Current − Continuous, max: -3 A
- Collector Dissipation: 30 W
- DC Current Gain (hfe): 40 to 250
- Transition Frequency, min: 3 MHz
- Operating and Storage Junction Temperature Range: -65 to +150 °C
