HBDS1-AY-11D/24V/R Plastic Body Round Push Button Switch with Red Indicator
Specification:-
- Product model: HBDS1-AY-11D/24V/R
- Head Shape: Round
- Mounting Hole Size: 16mm
- Rated Voltage: 24V
- Rated Current: ≤20mA
- Waterproof: IP40/IP65
- Terminal type: Pin terminal
- Contact resistance: ≤50 mΩ
- Insulation resistance: ≥100MΩ
- Working environment temperature: -25℃～+65℃
SKU: HS9606A
HBDS1-AY-11D/24V/R Plastic Body Round Push Button Switch with Red Indicator
The HBDS1-AY-11D/24V/R Plastic Body Round Push Button Switch with Red Indicator is a compact, durable, and user-friendly control device designed for various industrial, commercial, and DIY applications. It features a high-visibility red LED indicator that provides immediate visual feedback when the button is engaged, making it ideal for stop signals, emergency cut-off controls, or alert systems in electrical panels and equipment. Operating at 24V DC, this momentary push button returns to its original position after being pressed, ensuring safe and temporary activation for machinery, alarms, or automation circuits. Constructed with a robust plastic body and silver alloy contacts, this push button switch delivers excellent conductivity and long service life, even in environments with frequent use. It includes a 1NO + 1NC configuration (one normally open and one normally closed contact), offering versatile wiring options for various control needs. The built-in LED indicator is energy-efficient, consuming less than 20mA of current, and has an impressive lifespan of approximately 50,000 hours, reducing maintenance requirements. The HBDS1-AY-11D/24V/R features a 16mm mounting diameter and pin-type terminals for easy integration into control panels or enclosures. With its reliable functionality, clear signaling, and ease of installation, it is a practical solution for ensuring operational safety and status clarity in any system.
Feature:-
- Momentary Operation
- Durable Plastic Body
- Panel Mount Design
- Dust and Moisture Resistant
- Space-saving design fits well in confined panel layouts.
