IRF740 400V 10A N-Channel Power MOSFET (TO-220 Package)
Specification:-
- Number of Channels: 1 Channel
- Transistor Polarity: N-Channel
- Drain-Source Breakdown Voltage (Vds): 400V
- Continuous Drain Current (Id): 10A
- Drain-Source Resistance (Rds On): 0.54 Ohms
- Gate-Source Voltage (Vgs): 20V
- Gate Charge (Qg): 53 nC
- Operating Temperature Range: -55 – 150°C
- Power Dissipation (Pd): 134W
SKU: AQ8542A
IRF740 400V 10A N-Channel Power MOSFET (TO-220 Package)
The IRF740 is a 400V, 10A N-Channel Power MOSFET in a TO-220 package designed for use in high-voltage power switching applications. With its 400V drain-to-source voltage rating, it is suitable for circuits requiring robust voltage handling, such as power supplies, motor control, lighting control, and audio amplifiers. The 10A continuous drain current capability makes it versatile in mid-power applications, providing efficient switching in both low-side and high-side configurations. The N-Channel MOSFET is commonly used for low-side switching, where it is positioned between the load and ground, allowing the gate to be driven with a voltage higher than the source. This feature enables the IRF740 to provide excellent switching characteristics, making it ideal for DC-DC converters, inverters, and high-efficiency power supplies. The IRF740 features a low on-resistance, which helps minimize power dissipation during operation, reducing heat generation and improving efficiency. This is particularly important in high-current applications where thermal management is a key factor.
Features:-
- Low gate charge
- Low Crss (typical 35 pF)
- Fast switching
- Ease of paralleling
- Simple Drive Requirements
