IRFI644 250V 7.9A N-Channel Power MOSFET (TO-220 package)
Specification:-
- Number of Channels: 1 Channel
- Transistor Polarity: N-Channel
- Drain-Source Breakdown Voltage (Vds): 250V
- Continuous Drain Current (Id): 7.9A
- Drain-Source Resistance (Rds On): 0.28mOhms
- Gate-Source Voltage (Vgs): 20V
- Gate Charge (Qg): 68 nC
- Operating Temperature Range: -55 – 175°C
- Power Dissipation (Pd): 40W
SKU: KD8542A
IRFI644 250V 7.9A N-Channel Power MOSFET (TO-220 package)
The IRFI644 is a 250V, 7.9A N-Channel Power MOSFET housed in a TO-220 package, designed for medium-voltage and moderate-current power applications. It offers a drain-to-source voltage rating of 250V which makes it suitable for use in power electronics circuits that operate within this voltage range. The 7.9A continuous drain current rating ensures that it can handle significant power loads in a variety of applications. The IRFI644 features low on-resistance which reduces power loss and minimizes heating during operation. This characteristic is especially valuable in power conversion systems, as it improves overall efficiency. Additionally, it boasts a fast switching speed with low gate charge, making it well-suited for high-frequency applications, such as DC-DC converters, motor drives, and power supplies. Its TO-220 package provides superior thermal performance, allowing the device to efficiently dissipate heat, thus ensuring stable operation even under high power conditions. The package's robust design also offers ease of integration into power management systems, as it can handle the demands of both industrial and consumer electronics.
Features:-
- Dynamic dV/dt Rating
- Fast switching
- Advanced process technology
- Ultra Low On-Resistance
- Fully Avalanche Rated
