IRFP260N 200V 50A N-Channel Power MOSFET (TO-247 Package)
Specification:-
- Number of Channels: 1 Channel
- Transistor Polarity: N-Channel
- Drain-Source Breakdown Voltage (Vds): 200V
- Continuous Drain Current (Id): 50A
- Drain-Source Resistance (Rds On): 0.04 Ohms
- Gate-Source Voltage (Vgs): 20V
- Gate Charge (Qg): 234 nC
- Operating Temperature Range: -55 – 150°C
- Power Dissipation (Pd): 300W
SKU: EE8542A
IRFP260N 200V 50A N-Channel Power MOSFET (TO-247 Package)
The IRFP260N is a high-power N-Channel Power MOSFET designed for demanding applications that require high voltage and current handling capabilities. Encased in a durable TO-247 package, this MOSFET can withstand a maximum voltage of 200V and handle continuous currents of up to 50A under appropriate thermal management conditions. The IRFP260N is characterized by its ability to switch rapidly, which reduces switching losses and improves performance in fast-paced operations such as inverters, motor drives, and power supplies. It also boasts a high pulse current rating, making it reliable in circuits with transient surges. With its robust construction, the IRFP260N is capable of operating in challenging thermal and electrical environments. The TO-247 package includes a large tab for efficient heat dissipation, which is crucial for maintaining stability during high-power operation.
Features:-
- Dynamic dV/dt rating
- Repetitive avalanche rated
- Fast switching
- Ease of paralleling
- Simple Drive Requirements
