LM393 Linear Hall Effect Sensor Module

LM393 Linear Hall Effect Sensor Module

The LM393 Linear Hall Effect Sensor Module is a versatile and widely used sensor module that detects magnetic fields and converts them into a linear output voltage. This module is built around the LM393 dual comparator IC, which is responsible for processing the analog signal from the Hall Effect sensor and providing a digital output. The LM393 Hall Effect Sensor Module is designed to detect the presence of a magnetic field and measure its intensity. When a magnetic field is applied perpendicular to the sensor, the Hall Effect sensor generates a small voltage proportional to the strength of the magnetic field. This voltage is then processed by the LM393 IC, which outputs a digital signal that can be used in various electronic applications.

Applications:-

• Position Sensing
• Proximity Sensing
• Current Sensing
• Speed Sensing

Features:-

• High Sensitivity
• LED Indicator
• Wide Voltage Range
• Provides a clear high or low signal
