IC

TDA4864AJ Vertical deflection booster 7 pin IC pack of 2pcs

Specification

1. Operating supply voltage: 9V to 30V
2. Flyback generator output voltage: 2.2V
3. Supply current: 6mA to 10mA
4. Power amplifier with differential inputs
5. High vertical deflection frequency up to 200 Hz

LM3914 Logarithmic LED dot or bar display driver 18 pins IC pack of 50pcs

Specification

1. Analog controlled LED Driver IC
2. Number of controllable LEDs : 10
3. Operating voltage :  3V to 18V
4. Input analog voltage range : 1.2V to 12V
5. LED sink current :  2mA to 30mA (programmable)
6. Both Dot and Bar display mode available

LM741 Operational amplifier 8 pins IC pack of 50pcs

Specification

1. Operational amplifier
2. Number of pins : 8
3. Supply Voltage : 18V
4. Differential Input Voltage : 15V
5. Differential voltage amplification :  200V/mv
6. Supply Current :  1.5mA
7. Short circuit and overload protection
8. Low power consumption

UPC1230H2 25W Audio power amplifier bipolar analog 12 pins IC pack of 10pcs

Specification

1. Supply voltage range: 9.5V to 18V
2. Operating voltage: 16V
3. Circuit current: 4.5A
4. Power dissipation: 20W
5. Load impedance: 3.2Ω to 16Ω

24C08 8K Bit standard 2 wire bus interface serial DIP 8 pin IC pack of 2pcs

Specification

1. Low Voltage and Standard-Voltage Operation
2. 2-wire Serial Interface
3. Operating voltage : 2.7V to 5.5V
4. Clock frequency :  40KHz
5. Active current typical : 200µA
6. 100kHz and 400kHz Compatibility
7. 1024 x 8 bits for each

INA125P Instrumentation amplifier with precision voltage reference DIP 16 pin IC

Specification

1. Wide supply range:-
   • Single supply voltage : 2.7V to 36V
   • Dual supply voltage : 1.3v to 18V
2. Number of amplifier : 2
3. Input offset voltage :  250µV
4. Bandwidth : 150KHz
5. Slew rate :  0.02V/µs
6. Amplifier output : single-ended

TDA7294 100 watts Audio power amplifier 15 pins IC pack of 10pcs

Specification

1. Audio power amplifier
2. Supply voltage: 50 V
3. Output peak current : 10 A
4. Operating ambient temperature range : 0 to 70 °C
5. Open-loop voltage gain :  80 dB
6. Output power : up to 100 watts
7. Short circuit and thermal protection

TA8263BH 43W 4 Channel audio power amplifier bipolar linear 25 pins IC pack of 50pcs

Specification

1. Supply voltage range : 9V to 18V
2. Operating voltage : 15V
3. Power dissipation : 43W
4. High power output
5. Built-in diagnosis circuit
6. Low distortion ratio
7. Low noise

TOP246YN Extended power Flexible design, Eco-Smart, integrated off-line switcher 6 pin IC

Specification

1. Input supply voltage AC: 85V to 265V
2. Switching frequency: 66kHz - 132kHz
3. Output voltage : 12V
4. Operating supply current : 1.6mA
5. Drain voltage : 0.3V to 700V
6. Drain peak current : 4.32A
7. Type : Off line convertor
8. Extended power range
9. Wide duty cycle

PT2399 Digital delay echo audio processor DIP 16 pins IC pack of 50pcs

Specification

1. Audio echo processor IC for the digital delay
2. Supply voltage: 12V
3. Clock frequency:  4MHz
4. Maximum Voltage gain:  2.5dB
5. Power Supply Rejection Ratio: -40dB

TO-220 7805, 3-Terminal Positive Voltage Regulator IC pack of 5pcs

Specification

1. Output Current Up To 1.5 A
2. Input Voltage 4.8V To 5.2V
3. Thermal Overload Protection Short Circuit Protection
4. 2 % Output Voltage Tolerance
5. Output Transition SOA Protection

CD4017 Decade counter noise immunity DIP 16 pin IC pack of 2pcs

Specifications:-

1. Type : Decade counter IC
2. Supply voltage range : 5V to 15V
3. Power dissipation : 700mW
4. Supports 10 decoded outputs
5. High noise immunity : 0.45
6. Low power : 10 µW
7. Maximum clock frequency :  5.5Mhz
