IC

PS817 General purpose photocoupler DIP 4 Pin IC pack of 2pcs

Specification

1. Advance technology
2. Input diode forward voltage  :  1.25V
3. Collector-emitter voltage  :   80V
4. Collector current :  50mA
5. Cut-off frequency :  80 kHz
6. Rise time  :  18us
7. Fall time  :  18us

LM386 Low power audio frequency amplifier 8 pins IC pack of 50pcs

Specification

1. Low power audio frequency amplifier IC
2. Supply voltage : 4V to 15V
3. Quiescent power :  24mW at 6V
4. Analog input voltage :  0.4V
5. Voltage Gain :  20 to 200 (26dB to 46dB)
6. Speaker impedance :  4Ω
7. Short circuit protection outputs

TDA2050 32 watt Audio power amplifier 5 pins IC pack of 50pcs

Specification

1. Low-frequency class A and B amplifier
2. Operating voltage :  -25V to +25V
3. Output :  28Watts with 4Ω speaker
4. Voltage gain:  80dB
5. Supply voltage rejection:  45dB
6. Output power: up to 50 watts
7. Short circuit and thermal protection

2281 Dual channel LED lever meter driver monolithic DIP 16 pins IC pack of 10pcs

Specification

1. 100% Original and new product
2. Wide operating range:  5V to 14V
3. Power dissipation : 600mW
4. Voltage gain : 13.4 dB
5. Capable of driving red, green, and yellow LED's
6. High input impedance
7. Applicable to 10 dot mono output

TL494 Pulse Width Modulation Controlle IC

Specification:-

• Supply Voltage (VCC): 41V
• Amplifier input voltage: VCC+0.3V
• Collector output voltage: 41V
• Collector output current: 250 mA
• Lead temperature 1,6 mm: 260°C
• Storage Temperature: 65 °C to +150°C

HCNR200 High linearity analog optocouplers DIP 8 pin IC

Specification

1. Output type: Photodiode
2. Number of channels: 1
3. Isolation voltage: 5kV
4. If - Forward Current: 20 mA
5. Vf - Forward Voltage:  1.6 V
6. Power Dissipation: 60 mW

KA2206B 2.3W Dual audio power amplifier 14 pins IC pack of 50pcs

Specification

1. Supply voltage: 15V
2. Power dissipation: 4W
3. Operating supply voltage range: 9V to 11V
4. Quiescent circuit current : 40mA to 55mA
5. Closed loop voltage gain: 43dB to 47dB
6. Output power: 2.3W

INA125P Instrumentation amplifier with precision voltage reference DIP 16 pin IC

Specification

1. Wide supply range:-
   • Single supply voltage : 2.7V to 36V
   • Dual supply voltage : 1.3v to 18V
2. Number of amplifier : 2
3. Input offset voltage :  250µV
4. Bandwidth : 150KHz
5. Slew rate :  0.02V/µs
6. Amplifier output : single-ended

NE5532P low noise dual operational amplifier DIP 8 pin IC pack of 2pcs

Specification

1. Dual operational amplifier IC
2. Supply voltage  :  5V to 18V
3. DC voltage gain  :  5000
4. Unity gain bandwidth  :  10MHz
5. Slew rate :  9V/µs
6. P-P Output swing voltage :  26V

MAX705 Supervisory circuits power supply monitor with reset DIP 8 pin IC

Specification:-

1. Operating voltage range: 2V to 5.5V
2. Supply current: 150 µA
3. Reset threshold: 4.5V
4. Reset threshold hysteresis: 40mV
5. Reset pulse width: 280ms
6. Watchdog timeout period: 1.00 to 2.25 seconds

KA2224 Dual equalizer amplifier with ALC DIP 14 pin IC pack of 2pcs

Specification

1. Dual equalizer amplifier with in-built ALC circuit
2. Excellent channel separation
3. Supply voltage: 14V
4. Power dissipation: 600mW
5. ALC max. current: 3.5mA
6. Output voltage current: 1.2V

LM311 Differential comparator op-amp DIP 8 pin IC pack of 2pcs

Specification

1. Wide power supply Range
   1. Singe supply:  5V to 30V
   2. Dual supply : ±2.5V to ±15V
2. Maximum current : 7.5mA
3. Single supply for two op-amps enables reliable operation
4. Capable of driving load up to 50V and 50 mA
