SENSORS & MODULES

HX711 - Load cell voltage amplifier sensor module

Specifications:-

1. Input voltage: ±40mV
2. Data accuracy: 24 bit
3. Refresh frequency: 10 to 80 Hz
4. Operating voltage : 2.7V to 5V DC
5. Operating current: 10 mA

12V to 24V DC converter with 3 USB jacks for mobile charging application

Specification

1. Connector Type USB
2. Mounting Hardware 12v 3 USB Charger
3. Input Voltage 220 Volts (AC)
4. Total USB Ports 3
5. Output Current 2 Amps
6. Output Voltage 5 Volts

12v-24v DC converter with 4 USB Mobile Phone Charging application

Specification:-

• Connector Type: USB
• Input voltage: 12-24V DC
• Output: 5.2 V-3.4 Amp
• Included Components: 12v 4 USB Charger
• Easy to connect

4GB Micro SD HC Memory Card for Camera, Laptop, Mobile, Tablet

Specification:-

• Material: Plastic
• Color: Black
• Supply Type: Supplier
• Type: Sd Memory Card
• Fast Data Transfer

TPA3110 30W Mono (single) channel digital power amplifier modules pack of 10pcs

Specification

1. Chip name:  TPA3110
2. Working Voltage:  8V to 26 V DC
3. Output Power  :  30W
4. Applicable Speaker Impedance  :  8 Ω is perfect but 4/6 is also good
5. Single-channel digital power amplifier
6. Sound quality is also very good

P43 - Liquid and Water level float switch sensor module

Specifications:-

1. Maximum Load: 50 W
2. Max Switching Voltage: 100V DC
3. Minimum Voltage: 250V DC
4. Maximum Switching Current: 0.5 A
5. Max Load Current: 1.0 A
6. Max Contact Resistance: 0.4 ΩTemp Rating: -20~ 80 degree

ACS712 - 10A range current detection sensor module

Specifications:-

• Measures both AC and DC current
• Provides isolation from the load
• Easy to integrate with MCU, since it outputs an analog voltage
• Scale factor : 150mV/Amp

DC-DC Step-Up SX1308 Adjustable Power Module Step-Up Boost Converter

Specification:-

• Maximum Input Voltage: DC 2-24V
• Maximum Output Voltage: DC 2-28V
• Maximum Output Current: 2A
• Switching Frequency: 1.2MHz
• Maximum Conversion Efficiency: 95%

Single Channel 5V Relay Module low level trigger

Specification

1. Number of channels : 1
2. Operating voltage : 5V
3. Trigger voltage : 10V
4. Switching voltage : 250V at 10A
5. Equipped with high-current relay
6. It can control both AC and DC appliances such as Motors, lights, fans, etc.

2S 3A-9A 6.4V 32650,32700 Li-ion Lithium battery protection and charger BMS module JH886044 pack of 1pcs

Specification:-

1. Configuration: 2S (Two-cell series)
2. Current Range: 3A-9A
3. Voltage: 6.4V
4. Battery Type: 32650, 32700 Li-ion

Micro SD TF Card Memory Shield Module SPI Micro SD Adapter For Arduino

Specifications:-

1. Connects to Arduino using standard SPI pins.
2. Supports Micro SD and TF card formats.
3. Includes a built-in voltage level shifter for 5V and 3.3V systems.
4. Easily interfaces with Arduino for data storage and retrieval.

IIC or I2C Serial interface adapter module for 16 x 2 (1602) Character LCD display

Specifications:-

1. IC Name : PCF8574
2. Operating voltage : 5V
3. PCB size : 42mm x 20mm(L x B)
4. Serial I2C control of LCD display using PCF8574.
5. Backlight can be enabled or disabled via a jumper on the board.
6. Contrast control via a potentiometer.
