IRF840 500V 8A N-Channel Power MOSFET (TO-220 Package)
Specification:-
- Number of Channels: 1 Channel
- Transistor Polarity: N-Channel
- Drain-Source Breakdown Voltage (Vds): 500V
- Continuous Drain Current (Id): 8A
- Drain-Source Resistance (Rds On): 850mOhms
- Gate-Source Voltage (Vgs): 20V
- Gate Charge (Qg): 39 nC
- Operating Temperature Range: -55 – 175°C
- Power Dissipation (Pd): 125W
SKU: ZW8542A
IRF840 500V 8A N-Channel Power MOSFET (TO-220 Package)
The IRF840 is a 500V, 8A N-Channel Power MOSFET, housed in the compact and thermally efficient TO-220 package, making it ideal for use in high-voltage switching applications. Its combination of high breakdown voltage, moderate current handling, and low on-resistance ensures reliable and efficient operation across a range of power electronics. With a maximum drain-to-source voltage of 500V, the IRF840 is designed for applications requiring high voltage tolerance, such as power supplies, motor drivers, and inverters. Its continuous drain current of 8A allows it to handle moderate power loads, while its low R minimizes conduction losses, improving overall efficiency. The MOSFET's fast switching speed reduces switching losses, making it well-suited for high-frequency operation in DC-DC converters, lighting systems, and industrial controls. The TO-220 package provides excellent thermal performance and straightforward mounting options, ensuring reliable operation even under demanding conditions.
Features:-
- Dynamic dV/dt rating
- Repetitive avalanche rated
- Fast switching
- Ease of paralleling
