Specification:-
- Number of Channels: 1 Channel
- Transistor Polarity: N-Channel
- Drain-Source Breakdown Voltage (Vds): 100V
- Continuous Drain Current (Id): 35A
- Drain-Source Resistance (Rds On): 0.045 Ohms
- Gate-Source Voltage (Vgs): 20V
- Gate Charge (Qg): 55 nC
- Operating Temperature Range: -55 – 150°C
- Power Dissipation (Pd): 115W
SKU: TZ8542A
P30NF10/STP30NF10 100V 35A N-Channel Power MOSFET (TO-220 Package)
The P30NF10/STP30NF10 is a 100V, 35A N-Channel Power MOSFET housed in a TO-220 package, designed for use in high-current switching and power management applications. With a drain-to-source voltage rating of 100V and a continuous drain current of up to 35A, this MOSFET is well-suited for applications requiring robust performance, such as DC-DC converters, motor control circuits, power supplies, and inverters. The MOSFET features a low on-resistance, which ensures efficient current conduction, reduces power loss, and minimizes heat generation during operation. Its fast switching speed makes it ideal for applications that require high switching frequencies, ensuring precise control and improved energy efficiency. The TO-220 package provides excellent thermal performance, allowing effective heat dissipation during high-power operation. This enables the MOSFET to handle high levels of power without compromising reliability, making it a durable choice for demanding environments. Applications for the P30NF10/STP30NF10 include high-efficiency power management, solar inverters, uninterruptible power supplies (UPS), and automotive electronics, where high current capacity and reliability are crucial.
Features:-
- Switching application
- Exceptional dv/dt capability
- Fast switching
- Ease of paralleling
