IC

TC4420 6A High-Speed MOSFET Driver IC

Specification:-

• Supply Voltage: +20V
• Input Voltage: – 5V to VDD + 0.3V
• Input Current (VIN > VDD): 50 mA
• High Capacitive Load Drive Capability: 10,000 pF
• Wide Input Supply Voltage Operating Range: – 4.5V to 18V
• Package Power Dissipation 5-Pin TO-220 (With Heatsink): 12.5W
• Output Voltage Swing to Within 25 mV of Ground or VDD
• Thermal Impedances (To Case) 5-Pin TO-220: 10°C/W

CA3102E Dual High Frequency Differential Op-Amplifier IC (DIP-14 Package)

Specification:-

• Collector-to-Emitter Voltage : 15V
• Collector-to-Base Voltage: 20V
• Collector-to-Substrate Voltage: 20V
• Emitter-to-Base Voltage: 5V
• Collector Current, IC: 50 m A
• Temperature Range: -55°C to 125°C
• Maximum Power Dissipation 300mW
• Maximum Junction Temperature: 150°C
• Maximum Storage Temperature Range: -65°C to 150°C

74LS147 Dual Decimal to BCD Priority Encoder IC DIP-16 Package

Specification:-

• Number of pins: 16
• Supply Voltage (VCC): 4.75 to 5.25V
• Output Current (High): 8mA
• Output Current (Low): 70 µA
• Operating free-air temperature range: -400°C

CD4051 Single 8-channel Multiplexer/Demultiplexer IC (DIP-16 Package)

Specification:-

• Bandwidth: 20 MHz
• Supply curren: 0.04 uA
• 100% Tested for Quiescent Current at 20 V
• 5 V, 10 V, and 15 V Parametric Ratings
• Maximum Input Current of 1 µA at 18
• Input/output continuous current (Max): 10 mA
• Temperature range : -55°C to 125°C

INA122 Single Supply Instrumentation Op-Amplifier IC (DIP-8 Package)

Specification:-

• Low offset voltage: 175 μV maximum
• Wide Supply Range:  2.2V to 36V
• Dual Supply: –0.9/+1.3V to ±18V
• Low Offset Voltage: 250-μV Maximum
• Low Offset Drift: 3-μV/°C Maximum
• Low Noise: 60 nV/√Hz
• Low Input Bias Current: 25-nA Maximum
• Storage temperature: -40°C to 85 °C

CD4026 Decade Counter/Divider IC (DIP-16 Package)

Specification:-

• Type: Decade
• Function: Counter
• Supply Voltage:  3V to +18V
• 5-V, 10-V, and 15-V parametric ratings
• Operating temperature range: -55°C to +125°C
• Fully static counter operation: DC to 6 MHz (typ.) at VDD = 10 V

TO-92 78L06, 3-Terminal Positive Voltage Regulator IC pack of 5pcs

Specification

1. Output Current Up To 1.5 A
2. Input Voltage 5.76V To 6.24V
3. Thermal Overload Protection Short Circuit Protection
4. 2 % Output Voltage Tolerance
5. Output Transition SOA Protection

H8C1VB Encoder DIP 9 pins IC (Pack -50)

specification:

• Supply voltage:   2.4v& 12v
• Material:    plastic package with metal pins.
• chip of a semiconductor
• High quality product
• Bettar work with HT12D Dicoder

74HC08 Quad 2-Input AND Gate SMD IC

Specification:-

• Mounting: SMD
• Number of: 14 Pins
• Voltage Rating: 2.0 to 6.0V
• Storage Temperature Range: 0°C to + 70°C
• Large Operating Voltage Range

TL084 Quad JFET Input Operational Amplifier IC (DIP-14 Package)

Specification:-

• Number of channels: 4
• Iq per channel: 1.4 (mA)
• Rail-to-rail In to V+
• Low Input Bias Current: 30 pA Typical
• Low Input Offset Current: 5 pA Typical
• Low Power Consumption: 1.4 mA/ch Typical

CD40106 Hex Schmitt Trigger Inverter IC (DIP-14 Package)

Specification:-

• Input type: Schmitt-Trigger
• Output type: Push-Pull
• Supply voltage range: 3V to 18V
• Data rate: 24 (Mbps)
• Hysteresis Voltage (Typical):
• 0.9 V at VDD = 5 V
• 2.3 V at VDD = 10 V
• 3.5 V at VDD = 15 V
• 5-V, 10-V, and 15-V Parametric Ratings
• For Quiescent Current at 20 V

ULN2803 8 Darlington Transistor Arrays IC (DIP-18 Package)

Specification:-

• Output sustaining voltage: -0.5 to 50 V
• Output current: 500 mA/ch
• Input voltage: -0.5 to 30 V
• Clamp diode reverse voltage: 50 V
• Clamp diode forward current: 500 mA
• Power dissipation: 1.47 W
• Operating temperature: -40 to 85 °C
• Storage temperature: -55 to 150 °C
