IC

UC3844 SOP-8 Current Mode PWM Controller SMD IC

Specification:-

• Operating Frequency: 500 kHz
• Low Start Up Current
• Maximum Duty Clamp
• UVLO with Hysteresis
• Fixed Frequency Current-Mode PWM Controller

TO-92 78L08, 3-Terminal Positive Voltage Regulator IC pack of 5pcs

Specification

1. Output Current Up To 1.5 A
2. Input Voltage 7.7V To 8.3V
3. Thermal Overload Protection Short Circuit Protection
4. 2 % Output Voltage Tolerance
5. Output Transition SOA Protection

74HC148 8 to 3 Line Priority Encoder IC DIP-16 Package

Specification:-

• Number of pins: 16
• Current Rating: 8mA
• Voltage Rating: 2 to 6V
• Propagation Delay: 16ns
• Operating Temperature (°C): − 40°C to + 85°C

CNY74-4 IC – 4-Channel Optocoupler with Phototransistor IC

Specification:-

• Reverse voltage: 6V
• Forward current: 60mA
• Surge current: 1.5A
• Power dissipation: 100mW
• Collector-emitter breakdown voltage: 70V
• Emitter-base breakdown voltage: 7V
• Collector current: 100mA
• Junction temperature: 125°C

INA122 Single Supply Instrumentation Op-Amplifier IC (DIP-8 Package)

Specification:-

• Low offset voltage: 175 μV maximum
• Wide Supply Range:  2.2V to 36V
• Dual Supply: –0.9/+1.3V to ±18V
• Low Offset Voltage: 250-μV Maximum
• Low Offset Drift: 3-μV/°C Maximum
• Low Noise: 60 nV/√Hz
• Low Input Bias Current: 25-nA Maximum
• Storage temperature: -40°C to 85 °C

H8C1VB Encoder DIP 9 pins IC (Pack -1)

Specification:

• chip of a semiconductor
• High quality product
• Bettar work with HT12D Dicoder
• Good ripple rejection
• Low noise

CA3140 BiMOS Op-Amplifier SMD IC

Specification:-

• Supply voltage: 4V to 36V
• Directly Replaces Industry Type 741 in Most Application
• Operation at supply voltages up to 36V (18V).
• Very High Input Impedance (ZIN) -1.5T (Typ)
• Very Low Input Current -10pA (Typ) at 15V

IR2110 High and Low Side Driver IC (DIP-14 Package)

Specification:-

• High side floating supply voltage: -0.3 to 625 V
• High side floating supply offset voltage: VB -25 to VB +0.3 V
• High side floating output voltage: -0.3 to VB +0.3 V
• Low side and logic fixed supply voltage: -0.3 to 25V
• Low side output voltage: -0.3 to VCC+0.3 V
• Logic supply Voltage: -0.3 to VSS+25 V

24C02 2K bit Serial I2C Bus EEPROM IC DIP-8 Package

Specification:-

• Read current 1 mA, max.
• Single-Supply with Operation from: 4.5V to 5.5V
• All inputs and outputs w.r.t. VSS: -0.6V to VCC +1.0V
• Storage temperature: -65°C to +150°C
• Ambient temperature with power applied: 40°C to +125°C
• ESD protection on all pins: ≥ 4 kV

CA3102E Dual High Frequency Differential Op-Amplifier IC (DIP-14 Package)

Specification:-

• Collector-to-Emitter Voltage : 15V
• Collector-to-Base Voltage: 20V
• Collector-to-Substrate Voltage: 20V
• Emitter-to-Base Voltage: 5V
• Collector Current, IC: 50 m A
• Temperature Range: -55°C to 125°C
• Maximum Power Dissipation 300mW
• Maximum Junction Temperature: 150°C
• Maximum Storage Temperature Range: -65°C to 150°C

ADC0809 8-Bit A/D Converter with 8-Channel Multiplexer IC (DIP-28 Package)

Specification:-

• Number of input channels: 8
• Interface: Parallel
• Power consumption: 15 mW
• Input type: Single-Ended
• 8-Channel Multiplexer with Address Logic
• Operating temperature range: -40°C to 85°C

74LS189 64-Bit RAM with 3-State Output IC DIP-16 Package

Specification:-

• Number of pins: 16
• Supply Voltage: 0.4 to 0.5V
• Output Short Circuit Current: -80mA
• Power Supply Current: 40mA
• 64-Bit Storage Capacity
