74 SERIES DIP IC

74LS10 Dual J-K Positive Edge-Triggered Flip-Flop IC DIP-16 Package

Specification:-

  • Number of pins: 16
  • Supply Voltage (VCC): 7 V
  • Input Voltage (VI): 7 V
  • Operating free-air temperature range: 0°C to 70°C
  • Storage temperature range: -65°C to 150°C
Available in Pack Of:

SKU: SP9018A

MRP Rs. 43.50
Rs. 29.00 (Incl. Tax)
Rs. 24.58 (+18% GST extra)
Rs. 24.58 / pack of 1 = Rs. 24.58 per piece
Buy to Get ₹0 off!
₹0 Special Discount Applied
Quantity
Add to Cart

74LS10  Dual J-K Positive Edge-Triggered Flip-Flop IC DIP-16 Package

The 74LS10 Dual J-K Positive Edge-Triggered Flip-Flop IC in a DIP-16 package is a widely used digital logic device designed to perform memory storage and state control in various electronic circuits. This integrated circuit contains two independent J-K flip-flops that are triggered on the positive edge of the clock signal, making it suitable for synchronous applications. Each flip-flop operates with J (set) and K (reset) inputs that control the state of the output. When the clock signal transitions from low to high, the output state is determined by the inputs at that moment. If the J input is high and the K input is low, the output will be set to high; if J is low and K is high, the output will reset to low. If both J and K are high, the flip-flop toggles its output. This capability makes the 74LS10 essential for designing counters, registers, and various state machines.

Features:-

  • DIP-16 Package
  • Low Power Consumption
  • High-Speed Performance
  • Wide Operating Voltage Range
  • Positive Edge Triggering
  • TTL Logic Compatibility
