Showing 1–12 of 949 results
.jpg)
-
![74595 8-Bit Serial-in/Serial or Parallel-Out Shift Register SMD IC]()
74595 8-Bit Serial-in/Serial or Parallel-Out Shift Register SMD IC
Rs. 29.00Specification:-
- Mounting: SMD
- Number of: 16 Pins
- Voltage Rating: 2.0 to 6.0 V
- Supply Voltage: – 0.5 to + 7.0
- Input voltage: – 0.5 to VCC + 0.5
- Output Voltage: – 0.5 to VCC + 0.5
- Input Current: ±20 mA
- Storage Temperature Range: 0°C to + 70°C
- Output Drive Capability: 15 LSTTL Loads
-
![CD4070 Quad 2-Input Exclusive-OR (XOR) Gate IC (DIP-14 Package)]()
CD4070 Quad 2-Input Exclusive-OR (XOR) Gate IC (DIP-14 Package)
Rs. 29.00Specification:-
- Inputs: 2
- LOGIC Circuit: XOR
- Voltage Rating: 3V to 15V
- Propagation Delay (tpd): 280ns
- Noise immunity: 0.45 VDD
-
![CD4538 Dual Precision Monostable Multi Vibrator IC (DIP-16 Package)]()
CD4538 Dual Precision Monostable Multi Vibrator IC (DIP-16 Package)
Rs. 29.00Specification:-
- Part number: CD4538
- Wide supply voltage range 3.0V to 15V
- High noise immunity 0.45 VCC (typ.)
- DC Supply Voltage (VDD): −0.5V to +18VDC
- Input Voltage (VIN): −0.5V to VDD + 0.5VDC
- Power Dissipation (PD) Dual-In-Line: 700 mW
- Lead Temperature (TL): 260°C
- Storage Temperature Range (TS): −65°C to +150°C
-
![AD737 RMS to DC Converter IC]()
AD737 RMS to DC Converter IC
Rs. 729.00Specification:-
- Supply Voltage: ±16.5 V
- Internal Power Dissipation: 200 mW
- Input Voltage: ±VS
- Output Short-Circuit Duration: Indefinite
- Differential Input Voltage: +VS and –VS
- Lead Temperature: 300°C
- Storage Temperature Range: −65°C to +125°C
- ESD Rating: 500V
- Low input bias current: 25 pA maximum
-
![74HC541 Octal 3-State Buffer/Line Driver SMD IC]()
74HC541 Octal 3-State Buffer/Line Driver SMD IC
Rs. 59.00Specification:-
- Mounting: SMD
- Input level: CMOS level
- Supply Voltage: 2 to 6V
- Output Current: ± 35 mA
- Supply Voltage: − 0.5 to + 7.0V
- Operating Temperature: 65°C to 150°C
-
![IR2111 Half Bridge Driver IC (DIP-8 Package)]()
IR2111 Half Bridge Driver IC (DIP-8 Package)
Rs. 159.00Specification:-
- High side floating supply voltage: -0.3 to 625 V
- High side floating supply offset voltage: VB -25 to VB +0.3 V
- High side floating output voltage: -0.3 to VB +0.3 V
- Low side and logic fixed supply voltage: -0.3 to 25V
- Low side output voltage: -0.3 to VCC+0.3 V
- Logic input Voltage: -0.3 to VSS+0.3 V
-
![74HC574 Tri State Octal D-Type Flip-Flop IC DIP-20 Package]()
74HC574 Tri State Octal D-Type Flip-Flop IC DIP-20 Package
Rs. 29.00Specification:-
- Number of pins: 20
- Mounting: Through Hole
- Wide operating voltage range: 2V–6V
- Supply Voltage (VCC): − 0.5 to + 7.0V
- Input Voltage (VIN): −1.5V to VCC + 1.5V
- DC Output Current, per pin (IOUT): ± 35 mA
- DC VCC or GND Current, per pin (ICC): ± 70 mA
- Power Dissipation: 600 mW
- Operating Temperature (°C): − 65°C to + 150°C
-
![LF351 Wide Bandwidth JFET Input Op-Amplifier IC (DIP-8 Package)]()
LF351 Wide Bandwidth JFET Input Op-Amplifier IC (DIP-8 Package)
Rs. 99.00Specification:-
- Supply Voltage Never to be Crossed: +/-18V
- Power Dissipation without Heatsink applied: 670 mW
- Differential Input Voltage: +/-30V
- Supply Voltage Range on Input Pin: +/-15V
- High Slew Rate 13 V/µs Typical
- Storage Temperature Range: -65° C to +150° C
- Storage temperature: 0 °C to 70 °C
-
![ADM1485AR 1/1 Transceiver Half Interface IC RS422, RS485 8-SOIC]()
ADM1485AR 1/1 Transceiver Half Interface IC RS422, RS485 8-SOIC
Rs. 500.00Specification:-
- Communication Standard: RS-422, RS-485
- Data Rate: Up to 5 Mbps
- Package: 8-pin SOIC
- Supply Current-Max: 2.2 mA
- Supply Voltage-Max: 5.25 V
- Supply Voltage-Min: 4.75 V
- Supply Voltage-Nom: 5 V
- Operating Temperature Range: -40°C to 85°C
-
![OP183GS General Purpose Amplifier Circuit Bipolar IC 8-SOIC]()
OP183GS General Purpose Amplifier Circuit Bipolar IC 8-SOIC
Rs. 500.00Specification:-
- Package: 8-SOIC (0.154", 3.90mm Width)
- Amplifier Type: General Purpose
- No. of Pins: 8-Pins
- Current - Input Bias: 300nA
- Current - Output / Channel: 50mA
- Current - Supply: 1.2mA
- Gain Bandwidth Product: 5MHz
- Mounting Type: Surface Mount
-
![ADM708TAR-TR Supervisor SMD IC 1-Channel 8-Pin SOIC]()
ADM708TAR-TR Supervisor SMD IC 1-Channel 8-Pin SOIC
Rs. 500.00Specification:-
- Package: SOIC-8 (0.154", 3.90mm)
- No. of Pins: 8
- Supply Current (Typ): 250 uA
- Output: Push-Pull, Push-Pull
- Supply Voltage-Max (Vsup): 5.5 V
- Supply Voltage-Min (Vsup): 3.15 V
- Supply Voltage-Nom (Vsup): 5 V
- Operating Temperature: -40°C to 85°C
-
![74LS21 Dual 4-input AND Gate IC DIP-14 Package]()
74LS21 Dual 4-input AND Gate IC DIP-14 Package
Rs. 29.00Specification:-
- Number of pins: 14
- Supply Voltage (VCC): 7 V
- Input Voltage (VI): 7 V
- Operating free-air temperature range: 0°C to +70°C
- Storage temperature range: –65°C to +150°C
