TRANSISTORS

15N120NDH Transistor IGBT with Diode 1200V 15A Transistor

Specifications

• Collector-Emitter Voltage: 1200V
• Collector Current: 15A
• Storage Temperature Range: -55 to + 150
• Diode Continuous Forward Current: 15A

13001 Epitaxial NPN transistor packs of 100pcs

Specification

1. Transistor type  :  Epitaxial NPN transistor
2. Collector Power Dissipation  :  0.8W
3. Collector-Base Voltage  :  600V
4. Collector-Emitter Voltage  :  400 V
5. Emitter-Base Voltage  :  9V
6. Collector Current  :  0.5A

A966 Bipolar PNP transistor pack of 20pcs

Specifications:-

1. Transistor type:  bipolar PNP transistor
2. Collector-Emitter Voltage:  -30V
3. Collector-Base Voltage:  -30V
4. Emitter-Base Voltage:  -5V
5. Collector Current:  -1.5A
6. Collector Dissipation:   -0.9W
7. DC Current Gain:  - 100 to 320
8. Transition Frequency:  - 120MHz

A1015 Audio frequency amplifier PNP transistor pack of 20pcs

Specification:-

1. Transistor type  :  Audio frequency amplifier PNP transistor
2. Power dissipation  :  0.4W
3. High voltage  :  50v
4. High current  :  150mA
5. Collector power dissipation  :  400mW
6. DC current gain  :  400

BF422 Bipolar High voltage NPN transistor pack of 20pcs

Specification:-

1. Transistor type  :  High voltage NPN transistor
2. Maximum Collector power dissipation  :   0.83W
3. Maximum Collector-Base voltage  :  250V
4. Maximum Collector-Emitter voltage  :  250V
5. Maximum Emitter-Base voltage  :  5V
6. Maximum Collector current   :  0.05A
7. Transition frequency  :  60 MHz
8. Collector capacitance  :  1.6 pF

C1815 General purpose NPN transistors pack of 100pcs

Specification

1. Transistor type:  general purpose NPN transistor
2. DC Current Gain:  70 to 700
3. Continuous Collector Current:  0.15A
4. Collector-Emitter voltage:  50V
5. Collector-Base voltage:  60V
6. Transition Frequency:  80MHz

2N5401 Power switch PNP transistor pack of 20pcs

Specifications:-

1. Transistor type  :  Power switch PNP transistor
2. DC Current Gain  :  100
3. Maximum voltage across collector and emitter  :  150V
4. Maximum current allowed trough collector  :  600mA
5. Maximum voltage across collector and base  :  160 V
6. Maximum voltage across base and emitter  :  5V

5 mm infrared receiver black color 2 pin pack of 5pcs

Specification:-

1. Spectral range  :  700-1050
2. Light Current  :   ≥3mA
3. Breakdown Voltage  :  30
4. Maximum forward current   :  25mA
5. Power dissipation  :  100
6. Maximum reverse voltage  :  5V
7. Maximum Forward Voltage  :  1.2 V-1.3V
8. Package includes : 5 pieces

A42 Bipolar NPN transistor pack of 20pcs

Specification:-

1. Transistor type:  Bipolar NPN Transistor
2. DC Current Gain:  40
3. Continuous Collector Current:  500mA
4. Base- Emitter Voltage:  6V
5. Collector-Emitter Voltage:  300V

BC558 Bipolar amplifier PNP transistor packs of 100pcs

Specifications:-

1. Transistor type  :  PNP Amplifier Transistor
2. DC Current Gain  :  800
3. Continuous Collector current  :  100mA
4. Peak Collector current  :  200mA
5. Emitter Base Voltage  :  5V
6. Base Current  :  200mA peak

D882 Medium power NPN transistor packs of 100pcs

Specifications:-

1. Transistor type:  D882 Medium power NPN transistor
2. Max Collector Current:  3A
3. Max Collector-Emitter Voltage:  30V
4. Max Collector-Base Voltage:  40V
5. Max Emitter-Base Voltage:  5V
6. Max Collector Dissipation:  10 Watts

TL431 100mA NPN Regulator SMD Transistors 37V (SOT-23 Package) Pack of 10

Specification:-

• Type of transistor: NPN
• Collector-Emitter Voltage, max:  37 V
• Transition Frequency, min: 100 MHz
• Power dissipation: 300 mW
• Operating and Storage Junction Temperature Range: -65 to +150 °C
• Package: SOT-23
