TRANSISTORS

TIP31C NPN Transistors 100V (TO-220 Package) Pack of 100

• Transistor Polarity - NPN
• Collector-Emitter Voltage (VCEO) - 100V
• Continuous Base Current (IB) - 1A
• Continuous Collector Current (IC) - 3A
• Emitter cut-off current (IC) - 500mA
• Operating Temperature Range - (-65 - 150°C)
• Transition Frequency (fT) - 3MHz

TT2140 1500V NPN Power Transistor (TO-220 Package) Pack of 5

Specification:-

• Package Type:TO-220
• Type: NPN Transistor
• Max. Collector Current: 15A
• Max. Collector Power Dissipation (Pc): 30 W
• Max. Collector-Base Voltage (Vcb): 1500 V
• Max. Collector-Emitter Voltage (Vce): 800 V
• Max. Emitter-Base Voltage (Veb): 6 V
• Max. Collector Current (Ic max): 6 A
• Operating Temperature Range: -55°C to +150°C

BC547 Bipolar NPN transistors box of 2000pcs

Specification

1. Transistor type:  Bipolar NPN Transistor
2. DC Current Gain:  800
3. Continuous Collector current  :  100mA
4. Emitter Base Voltage  :  6V
5. Base Current  :  5mA

Si2302ds 20V SOT-23 N-Channel Mosfet Pack of 10pcs

Specification :-

• Drian Source Voltage - 20v
• Drian Current - ±8mA
• Static Drain–Source On Resistance - RDS(on)1=VGS=4.5V ID=3.6AmA
• Fast Switching speed
• Case: SOT23

BF494 Medium frequency NPN transistor packs of 100pcs

Specification:-

1. Transistor type  :  Medium frequency NPN transistor
2. Collector-Base Voltage  :  30V
3. Collector-Emitter Voltage  :  20V
4. Emitter-Base Voltage  :  5V
5. Continuous Collector Current  :  30mA

TIP31 Medium power NPN transistor pack of 5pcs

Specification:-

1. Transistor type Medium power NPN transistor
2. Current gain  :  50
3. The maximum voltage across collector-emitter  :  100V
4. Maximum current allowed through collector  :  3A DC

TIP41C General purpose NPN transistor packs of 50pcs

Specification

1. Transistor type:  General purpose NPN transistor
2. Max Collector Current:  6A
3. Max Collector-Emitter Voltage  :  100V
4. Max Collector-Base Voltage  :  100V
5. Max Emitter-Base Voltage  :  5V
6. Max Collector Dissipation  :  65W
7. Max Transition Frequency  :  3MHz

BD139 Medium power NPN transistors box of 2000pcs

Specification:-

1. Transistor type  :  Medium power NPN transistor
2. Continuous collector current  :  1.5A
3. Collector-Emitter voltage  :  80 V
4. Collector-Base voltage  :  80V
5. Emitter Base Breakdown Voltage  :  5V
6. DC current gain  :  40 to 160

2N6107 PNP Transistors 70V (TO-220 Package) Pack of 5

• Transistor Polarity - PNP
• Collector-Emitter Voltage (VCEO) - 70V
• Continuous Base Current (IB) - 3A
• Continuous Collector Current (IC) - 7A
• Emitter cut-off current (IC) - 500mA
• DC Current Gain (hFE) - 2
• Operating Temperature Range - (-65 - 150°C)
• Transition Frequency (fT) - 10MHz

2N3904 Bipolar General purpose NPN transistor packs of 100pcs

Specification

1. Transistor type  : Bipolar NPN Transistor
2. DC Current Gain  :  300
3. Continuous Collector current  :  200mA
4. Base- Emitter Voltage  :  6V
5. Collector-Emitter Voltage  :  40V
6. Collector-Base Voltage  :  60V

M28S 1000mA 20V SOT-23 NPN Bipolar transistors pack of 5pcs

Specification

1. Type of transistor: NPN
2. Polarisation: bipolar
3. Collector-emitter voltage: 20V
4. Power dissipation: 200mW
5. Case: SOT23
6. Frequency: 100MHz
7. Gain H(fe): 300/1000
8. Collector current: 1000mA

BC327, -800mA, -45V TO-92 Package General purpose PNP transistor pack of 10 pcs

Specification

1. Type:   Transistor
2. Polarity:   PNP
3. Collector - Emitter voltage:  -800 volts
4. Collector current:   45 mA
5. Gain H(fe):  100/630
6. Power dissipation:  625 mW
7. F(t) minimum:  50 MHz
8. Package: TO-92
9. Max Storage & Operating temperature Should Be: -55 to +150 Centigrade
