TRANSISTORS

BC856, -100mA, -65V TO-92 Package General purpose PNP transistor pack of 10pcs

Specification

1. Type:   Transistor
2. Polarity:   PNP
3. Collector - Emitter voltage: -65 volts
4. Collector current:   -100 mA
5. Gain H(fe):  110/800
6. Power dissipation:  625 mW
7. F(t) minimum:  100 MHz
8. Package: TO-92
9. Max Storage & Operating temperature Should Be: -55 to +150 Centigrade

TIP41C General purpose NPN transistors box of 100pcs

Specification:-

1. Transistor type  :  General purpose NPN transistor
2. Max Collector Current  :  6A
3. Max Collector-Emitter Voltage  :  100V
4. Max Collector-Base Voltage  :  100V
5. Max Emitter-Base Voltage  :  5V
6. Max Collector Dissipation  :  65W
7. Max Transition Frequency  :  3MHz

A92 High voltage PNP transistor packs of 100pcs

Specifications

1. Transistor type  :  High Voltage PNP Transistor
2. Collector-Emitter voltage  :  300 V
3. Emitter Base Voltage  :  5V
4. Continuous Collector current  :  500mA
5. Transition Frequency  :  50MHz

BF422 Bipolar High voltage NPN transistors pack of 100pcs

Specification:-

1. Transistor type  :  High voltage NPN transistor
2. Maximum Collector power dissipation  :   0.83W
3. Maximum Collector-Base voltage  :  250V
4. Maximum Collector-Emitter voltage  :  250V
5. Maximum Emitter-Base voltage  :  5V
6. Maximum Collector current   :  0.05A
7. Transition frequency  :  60 MHz
8. Collector capacitance  :  1.6 pF

C2482 High voltage NPN transistor packs of 100pcs

Specification

1. Transistor type:  NPN transistor
2. Collector-Emitter Voltage:  300V
3. Collector-Base Voltage  :  300V
4. Emitter-Base Voltage  :  7V
5. Collector Current  :  0.1A
6. Collector Dissipation  :  - 0.9W
7. DC Current Gain  :  - 30 to 150

BF421 High voltage PNP transistor pack of 20pcs

Specification

1. Transistor type:  High voltage PNP transistor
2. Maximum Collector Power Dissipation:   0.83W
3. Maximum Collector-Base Voltage  :  300V
4. Maximum Collector-Emitter Voltage  :  300V
5. Maximum Emitter-Base Voltage  :  5V
6. Maximum Collector Current   :  0.025A
7. Transition Frequency  :  60 MHz
8. Collector Capacitance  :  1.6 pF

2N5401 Power switch PNP transistor packs of 100pcs

Specifications:-

1. Transistor type:  Power switch PNP transistor
2. DC Current Gain:  100
3. Maximum voltage across collector and emitter  :  150V
4. Maximum current allowed trough collector  :  600mA
5. Maximum voltage across collector and base  :  160 V
6. Maximum voltage across base and emitter  :  5V

S8550 Audio amplifier PNP transistor packs of 100pcs

Specifications

1. Transistor Type:  PNP transistor
2. Max Collector Current(I_C)  :  -0.7A or -700mA
3. Max Collector-Emitter Voltage (V_CE)  :  -20V
4. Max Collector-Base Voltage (V_CB)  :  -30V
5. Max Emitter-Base Voltage  :  -5V
6. Max Collector Dissipation  :  1 Watt
7. Transition Frequency  :  100 MHz

2N5296 NPN Transistors 40V (TO-220 Package) Pack of 100

Specification:-

• Transistor Polarity - NPN
• Collector-Emitter Voltage (VCEO) - 40V
• Continuous Base Current (IB) - 2A
• Continuous Collector Current (IC) - 1A
• Emitter cut-off current (IC) - 200mA
• DC Current Gain (hFE) - 30-120
• Operating Temperature Range - (-65 - 150°C)

BC548 100mA 30V TO-92 Package General purpose NPN transistor pack of 10 pcs

Specification

1. Collector-Emitter Voltage (VCEO): 30V
2. Continuous Collector Current (IC):  100mA
3. Transition Frequency (fT):  250MHz
4. DC Current Gain (hFE): 110-800
5. Operating Temperature Range: -55 - 150°C
6. Transistor type  :  NPN Transistor

BU407 NPN Transistors 150V (TO-220 Package) Pack of 100

• Transistor Polarity - NPN
• Collector-Emitter Voltage (VCEO) - 150V
• Continuous Base Current (IB) - 4A
• Continuous Collector Current (IC) - 5A
• Emitter cut-off current (IC) - 500mA
• Operating Temperature Range - (-65 - 150°C)
• Transition Frequency (fT) - 10MHz

8050 Audio amplifier NPN transistor Packs of 100pcs

Specifications

1. Transistor Type:  NPN
2. Collector Current:  0.7A or 700 mA
3. Max Collector-Emitter Voltage (V_CE)  :  20V
4. Max Collector-Base Voltage (V_CB)  :  30V
5. Max Emitter-Base Voltage (VBE)  :  5V
6. Max Collector Dissipation (Pc)  :  1 W
7. Max Transition Frequency  :  100 MHz
