74LS126 Quad 3-State Buffer IC DIP-14 Package
Specification:-
- Number of pins: 14
- Supply Voltage (VCC): 4.75 to 5.25V
- Output Current (Low): 8mA
- Operating temperature range: 0°C to 70°C
- 3-State Output Control
SKU: LH9018A
74LS126 Quad 3-State Buffer IC DIP-14 Package
The 74LS126 Quad 3-State Buffer IC in a DIP-14 package is a high-performance logic IC from the 74LS series, designed to serve as a buffer with 3-state output control. It contains four independent buffer gates, each with a 3-state output controlled by a separate enable input. This feature makes the 74LS126 versatile for a range of applications where isolating signals or controlling data flow is essential, such as in bus-oriented systems or multiplexer configurations. Each buffer gate in the IC offers high-output drive capability, which enables it to drive larger loads effectively without significant loss in signal quality. The 3-state outputs allow the device to disconnect from the bus, providing an open-circuit condition when not enabled. This helps to prevent data conflicts on shared communication lines, ensuring stable data transfer and efficient resource management in complex digital systems.
Features:-
- DIP-14 Package
- Low Power Consumption
- High-Speed Performance
- Wide Operating Voltage Range
- 3-State Output Control
- Four Independent Buffers
