LOGIC IC
Showing 1–12 of 137 results
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
-
![74ACT374PC Flip Flop 1-Element D-Type Logic IC 8-Bit Positive Edge 20-PDIP]()
74ACT374PC Flip Flop 1-Element D-Type Logic IC 8-Bit Positive Edge 20-PDIP
Rs. 500.00Specification:-
- Package: PDIP20 (0.300", 7.62mm)
- Logic Type: D-Type Flip-Flop
- Number of Circuits: 8 Circuit
- Input Type: Single-Ended
- Polarity: Non-Inverting
- High Level Output Current: - 24 mA
- Low Level Output Current: 24 mA
- Supply Voltage - Min: 4.5 V
- Supply Voltage - Max: 5.5 V
-
![74HCT132D NAND Gate IC 4 Channel Schmitt Trigger Logic IC 14-SOIC]()
74HCT132D NAND Gate IC 4 Channel Schmitt Trigger Logic IC 14-SOIC
Rs. 500.00Specification:-
- Package: SOIC14 (0.154", 3.90mm)
- Logic Function: NAND
- Number of Output Lines: 1 Output
- Low Level Output Current: 6 mA
- High Level Output Current: - 6 mA
- Propagation Delay Time: 33 ns
- Supply Voltage - Min: 4.5 V
- Supply Voltage - Max: 5.5 V
-
![MM74HC4538MX Monostable Multivibrator Logic IC 26 ns 16-SOIC]()
MM74HC4538MX Monostable Multivibrator Logic IC 26 ns 16-SOIC
Rs. 500.00Specification:-
- Package: SOIC16 (0.154", 3.90mm)
- Propagation Delay Time: 275 ns, 55 ns, 47 ns
- Supply Current - Max: 130 mA
- Supply Voltage - Min: 2 V
- Supply Voltage - Max: 6 V
- Low Level Output Current: 5.2 mA
- High Level Output Current: - 5.2 mA
-
![74ACT02SCX Logic IC NAND Gate IC 4 Channel 14-SOIC]()
74ACT02SCX Logic IC NAND Gate IC 4 Channel 14-SOIC
Rs. 500.00Specification:-
- Package: SOIC14 (0.154", 3.90mm)
- Logic Function: NAND
- Number of Gates: 4 Gate
- Low Level Output Current: 24 mA
- High Level Output Current: - 24 mA
- Propagation Delay Time: 9.5 ns
- Supply Voltage - Min: 5.5 V
- Supply Voltage - Max: 4.4 V
-
![CD4089BE Binary Rate Multiplier Logic IC 16-PDIP]()
CD4089BE Binary Rate Multiplier Logic IC 16-PDIP
Rs. 500.00Specification:-
- Package: PDIP16 (0.300", 7.62mm)
- Input Frequency: DC to 3.5 MHz
- Supply Voltage-Max (Vsup): 18 V
- Supply Voltage-Min (Vsup): 3 V
- Supply Voltage-Nom (Vsup): 5 V
- Operating Temperature: -55°C ~ 125°C
-
![CD4063BE Magnitude Comparator Bit Active Logic IC High Output A<B, A=B, A>B 16-PDIP]()
CD4063BE Magnitude Comparator Bit Active Logic IC High Output A
Rs. 500.00Specification :-
- Package: PDIP16 (0.300", 7.62mm)
- Mounting Style: Through Hole
- Logic Function: A < B, A = B, A > B
- Propagation Delay Time: 140 ns, 175 ns
- Supply Voltage - Min: 3 V
- Supply Voltage - Max: 18 V
- Supply Current - Max: 100 uA
-
![CD4019BE AND/OR Gate Configurable 4 Circuit 2, 2 Input Logic IC 16-PDIP]()
CD4019BE AND/OR Gate Configurable 4 Circuit 2, 2 Input Logic IC 16-PDIP
Rs. 500.00Specification:-
- Package: PDIP16 (0.300", 7.62mm)
- Number of Circuits: 4
- Number of Inputs: 2
- Supply Voltage-Max (Vsup): 18 V
- Supply Voltage-Min (Vsup): 3 V
- Supply Voltage-Nom (Vsup): 5 V
- Operating Temperature: -55°C ~ 125°C
-
![DM7403N NAND Gate Logic IC 4 Channel Open Collector 14-PDIP]()
DM7403N NAND Gate Logic IC 4 Channel Open Collector 14-PDIP
Rs. 500.00Specification :-
- Package: PDIP14 (0.300", 7.62mm)
- Logic Function: NAND
- Number of Output Lines: 1 Output
- Low Level Output Current: 16 mA
- High Level Output Current: - 250 uA
- Propagation Delay Time: 45 ns
- Supply Voltage - Min: 4.75 V
- Supply Voltage - Max: 5.25 V
-
![MM74HC08MTCX AND Gate Logic IC 4 Channel 14-TSSOP]()
MM74HC08MTCX AND Gate Logic IC 4 Channel 14-TSSOP
Rs. 500.00Specification:-
- Package/Case: TSSOP14 (0.173", 4.40mm)
- Mounting Style: SMD/SMT
- Number of Output Lines: 4 Output
- Low-Level Output Current: 5.2 mA
- High-Level Output Current: - 5.2 mA
- Propagation Delay Time: 13 ns
- Supply Voltage - Min: 2 V
- Supply Voltage - Max: 6 V
-
![74F64PC AND/OR/INVERT Gate Configurable 1 Circuit 11 Input (4, 2, 3, 2) Input 14-PDIP]()
74F64PC AND/OR/INVERT Gate Configurable 1 Circuit 11 Input (4, 2, 3, 2) Input 14-PDIP
Rs. 500.00Specification:-
- Package/Case: PDIP14 (0.300", 7.62mm)
- Number of Output Lines: 1 Output
- Low Level Output Current: 20 mA
- High Level Output Current: - 1 mA
- Propagation Delay Time: 6.5 ns
- Supply Voltage - Min: 4.5 V
- Supply Voltage - Max: 5.5 V
-
![74ACT138SCX Logic IC Decoder/Demultiplexer 1 x 3:8 16-SOIC]()
74ACT138SCX Logic IC Decoder/Demultiplexer 1 x 3:8 16-SOIC
Rs. 500.00Specification:-
- Package: SOIC16 (0.154", 3.90mm)
- Mounting Style: SMD/SMT
- No. of Channels: 1 channel
- Supply Voltage - Min: 4.5 V
- Supply Voltage - Max: 5.5 V
- Operating Temperature: -40°C to 85°C
-
![CD4068BE NAND/AND Gate Configurable 1 Circuit 8 Input 14-PDIP]()
CD4068BE NAND/AND Gate Configurable 1 Circuit 8 Input 14-PDIP
Rs. 500.00Specification:-
- Package: PDIP14 (0.300", 7.62mm)
- Number of Output Lines: 1 Output
- Low Level Output Current: 6.8 mA
- High Level Output Current: - 6.8 mA
- Propagation Delay Time: 75 ns
- Supply Voltage - Min: 3 V
- Supply Voltage - Max: 18 V
